| Color Print Speed (ppm) |
27 |
| Mono Print Speed (ppm) |
31 |
| Processor |
533 MHz |
| Print Resolution (dpi) |
Up to 1200 x 600 |
| Duty Cycle (pg./mo.) |
Up to 60,000 |
| Connectivity |
USB v2.0 high-speed; 10/100 Base-TX Ethernet (network) |
| Network I/F |
10/100 Base-TX Ethernet (network) |
| Emulations |
PCL 5c, PCL 6; PostScript 3 emulation; SIDM |
| Operating Systems |
32-/64-bit - Windows 7, Vista, XP, Server 2008 and Server 2003; 64-bit - Server 2008 R2; Win 2000; Mac Support - OS 10.3.9 to 10.6 |
| Resident Scalable Fonts |
32-/64-bit - Windows 7, Vista, XP, Server 2008 and Server 2003; 64-bit - Server 2008 R2; Win 2000; Mac Support - OS 10.3.9 to 10.6 |
| Bitmap (PCL) Fonts |
OCR-A, OCR-B, Line Printer, USPS; Barcode - 12 types + PDF417 |
| Color Copy Speed (ppm) |
27 ppm |
| Mono Copy Speed (ppm) |
31 ppm |
| Scanning Speed |
Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi (simplex) |
| Scan Type |
Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi (simplex) |
| Scan Method |
TWAIN |
| Scan-to-PC |
Create electronic file from hard copy original in PDF, TIFF or JPEG file formats (TWAIN scanning driver included; Windows compatible) |
| Scan-to-Email Protocol |
Scan to e-mail with LDAP support |
| Scan-to-File Protocol |
Yes |
| Scan-to-File File Formats |
PDF, TIFF, JPEG, BMP, PCX, GIF, TGA, PNG, WMF, EMF |
| TWAIN Driver |
Windows 2000 and higher; enables remote preview and scan functionality via network |
| Address Book Management |
LDAP (Lightweight Directory Access Protocol) |
| Standard Imaging RAM (MB) |
256 |
| Maximum Imaging RAM (MB) |
768 |
| Scanner ADF |
LDAP (Lightweight Directory Access Protocol) |
| Maximum Page Size |
Main Tray from 4.1 x 5.8 inches to 8.5 x 14 inches; optional 2nd Tray from 5.8 x 8.3 inches to 8.5 x 14 inches; Multi-Purpose Tray (MPT) from 3 x 5 inches cards to 8.5 x 52 inches banners |
| Standard Printer Input |
350 sheets (250 sheets via Main Tray + 100 sheets via MPT) |
| Maximum Capacity |
880 sheets (with optional 530-sheet 2nd Paper Tray) |
| Multi Purpose Tray |
100 sheets |
| Paper Size |
Letter, Legal 13/13.5/14, Banner, Executive, A4, A5, A6, B5; Envelopes - C5, DL, Monarch, COM 9, COM 10 |
| Paper Weight |
Main Tray/Opt. 2nd Tray 17 lb. bond - 65 lb. cover (64-176 gsm); RADF 16 lb. - 28 lb. bond (60 - 105 gsm); MPT 17 lb. bond - 80 lb. cover (64- 220 gsm) |
| Number Trays |
2 |
| Paper Capacity |
150 sheets, face down output |
| Power Consumption |
Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W |
| Acoustic Noise |
Printing 54 dB; Copying 55.5 dB; Standby 37dB; Power Save - Inaudible |
| Dimensions (W x D x H) |
16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm) |
| Weight |
63 lbs (29 kg), including consumables |
