| Display Type |
Single 0.55" DMD DLP Technology by Texas Instruments |
| Resolution |
Native SVGA (800 x 600) |
| Maximum Resolution |
HD (1920 x 1080) |
| Brightness (Typical) |
2800 ANSI Lumens |
| Contrast Ratio |
3000:1 (Full On/Full Off) |
| Lamp Life and Type |
Estimated at 4000/3000 Hours (STD/Bright)
185W UHP |
| Throw Ratio |
1.95 to 2.15:1 (Distance/Width) |
| Projection Distance |
3.28' to 32.8' (1.0 to 10m) |
| Image Size (Diagonal) |
22.9" to 300" (0.58 to 7.62m) |
| Aspect Ratio |
4:3 Native, 16:9 and 16:10 Compatible |
| Remote Control |
IR Remote |
| Audio |
2-Watt Speaker |
| Displayable Colors |
1.07 Billion |
| Uniformity |
85% |
| Offset |
115% |
| Computer Compatibility |
HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) |
| Projection Lens |
F= 2.41-2.55, f= 21.8-23.98mm, 1.1x Manual Zoom and Focus |
| Monitor Loop Through |
D-Sub 15 pin VGA Output (Functional in Both Normal and Standby Modes) |
| User Controls |
Complete On-Screen Menu Adjustments in 23 Languages |
| I/O Connectors |
VGA-In, VGA-Out, S-Video, Composite Video, Stereo Audio-In, Stereo Audio-Out, RS-232 |
| Security |
Kensington Lock Port, Security Bar and Keypad Lock |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Noise Level (STD/Bright) |
28dB/30dB |
| Keystone Correction |
±40° Vertical |
| Horizontal Scan Rate |
15.3 - 91.1 KHz |
| Vertical Refresh Rate |
24 - 85 Hz |
| Operating Temperature |
41 to 104°F (5 to 40°C), 85% Max Humidity |
| Power Supply |
AC Input 100-240V, 50-60Hz, Auto-Switching |
| Power Consumption |
255 Watts (Bright), 230 Watts (STD), <1 Watt (Standby) |
| Dimensions (W x H x D) |
11.28" x 3.98" x 7.6" (287 x 101 x 193 mm) |
| Weight |
5 lbs (2.27kg) |
| Warranty |
Optoma 1 year limited parts and labor on projector & 90 days on lamp warranty |
