| Display Technology |
Single 0.55" DMD DLP Technology by Texas Instruments |
| Resolution |
Native XGA (1024 x 768) |
| Maximum Resolution |
UXGA (1600 x 1200) |
| Brightness (Typical) |
3500 ANSI Lumens |
| Contrast Ratio |
3000:1 (Full On/Full Off) |
| Lamp Life and Type |
4000/3000 Hours (STD/Bright) 230W P-VIP |
| Throw Ratio |
1.95 to 2.15:1 (Distance/Width) |
| Projection Distance |
3.93' to 39.3' (1.2 to 12m) |
| Image Size (Diagonal) |
27.5" to 303" (0.7 to 7.69m) |
| Aspect Ratio |
4:3 Native, 16:9 and 16:10 |
| Audio |
2-Watt Speaker |
| Offset |
115% |
| Displayable Colors |
1.07 Billion |
| Uniformity |
85% |
| Remote Control |
IR Remote Control |
| Computer Compatibility |
UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) |
| Loop Through |
Monitor: D-Sub 15-Pin VGA Output Audio: Mini-Jack Stereo Output (Functional in Both Normal and Standby Modes) |
| Projection Lens |
F=2.4-2.55, f=21.8-24mm, 1.1x Manual Zoom and Focus |
| User Controls |
Complete On-Screen Menu Adjustments in 23 Languages |
| I/O Connectors |
Two VGA-In, VGA-Out, S-Video, Composite Video, Stereo Audio-In, Stereo Audio-Out, RS-232 and USB |
| 3D Compatibility |
120Hz Frame Sequential 3D for Resolutions Up to 720p, 60Hz Field Sequential 3D for Resolutions Up to 480i |
| Security |
Kensington Lock, Security Bar and Keypad Lock |
| Projection Options |
Front, Rear, Ceiling Mount, Table Top |
| Noise Level (STD/Bright) |
29dB/31dB |
| Keystone Correction |
±40 Deg. Vertical |
| Horizontal Scan Rate |
15.3 to 91.1 KHz |
| Vertical Refresh Rate |
24 to 85 Hz, 120 Hz |
| Operating Temperature |
41 to 104 Deg.F (5 to 40 Deg.C), 80% Max Humidity |
| Power Supply |
AC Input 100-240V, 50-60Hz, Auto-Switching |
| Power Consumption |
295 Watts (Bright), 243 Watts (STD), <1 Watt (Standby) |
| Dimensions (W x H x D) |
12.76" x 3.82" x 9.21" (324 x 97 x 234 mm) |
| Weight |
6.4 lbs (2.9kg) |
