| Display Type |
Single 0.55" DMD DLP Technology by Texas Instruments |
| Resolution |
Native XGA (1024 x 768) |
| Maximum Resolution |
UXGA (1600 x 1200) |
| Brightness (Typical) |
3000 ANSI Lumens |
| Contrast Ratio |
2500:1 (Full On/Full Off) |
| Lamp Life and Type |
Estimated at 3000/2000 Hours (STD/Bright) 220W SHP |
| Throw Ratio |
1.8 to 2.2:1 (Distance/Width) |
| Projection Distance |
3.9' to 39.4' (1.2 to 12m) |
| Image Size (Diagonal) |
26.87" to 311.1" (0.68 to 7.9m) |
| Aspect Ratio |
4:3 Native, 16:9 and 16:10 Compatible |
| Remote Control |
Fully Featured IR Remote with Laser Pointer and Mouse |
| Audio |
One 1-Watt Speaker |
| Displayable Colors |
134 Million |
| Offset |
114% |
| Computer Compatibility |
UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) |
| Projection Lens |
F= 2.55-2.72, f= 21.3-24.5 mm, 1.15x Manual Zoom and Focus |
| User Controls |
Complete On-Screen Menu Adjustments in 22 Languages |
| I/O Connectors |
HDMI v1.3, VGA-In, Composite Video, S-Video, Audio-In and USB |
| Security |
Kensington Lock Port |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Noise Level (STD/Bright) |
33dB/36dB |
| Horizontal Scan Rate |
15, 30 - 91.4 KHz |
| Vertical Refresh Rate |
43 - 87 Hz |
| Keystone Correction |
± 30° Vertical |
| Uniformity |
85% |
| Operating Temperature |
41 to 104°F (5 to 40°C), 80% Max Humidity |
| Power Supply |
AC Input 100-240V, 50-60Hz, Auto-Switching |
| Power Consumption |
280 Watts (Bright), 230 Watts (STD), <5 Watts (Standby) |
| Dimensions (W x H x D) |
8.66" x 2.79" x 7.0" (220 x 71 x 178 mm) |
| Weight |
3.2 lbs (1.4kg) |
| Warranty |
Optoma 3 years express replacement service on projector & 1 year lamp warranty |
