| Display Technology |
Single 0.7" DMD DLP Technology by Texas Instruments |
| Native Resolution |
XGA (1024 x 768) |
| Maximum Resolution |
HD (1920 x 1080) |
| Brightness (Typical) |
5000 ANSI Lumens |
| Contrast Ratio |
3000:1 (Full On/Full Off) |
| Lamp Life and Type |
3000/2000 Hours (STD/Bright)
280W P-VIP |
| Throw Ratio |
1.8 to 2.1:1 (Distance/Width) |
| Projection Distance |
3.28' to 32.8' (1.0 to 10m) |
| Image Size (Diagonal) |
23.4" to 300" (0.59 to 7.62m) |
| Offset |
112% |
| Displayable Colors |
1.07 Billion |
| Uniformity |
80% |
| Audio |
3-Watt Speaker |
| Noise Level (STD/BRIGHT) |
28dB/30dB |
| Remote Control |
IR Remote Mouse with Laser Pointer |
| Computer Compatibility |
HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) |
| 3D Compatibility |
120Hz Frame Sequential 3D for Resolutions Up to 720p, 60Hz Field Sequential 3D for Resolutions Up to 480i |
| Monitor Loop Through |
D-Sub 15-Pin VGA Output (Functional in Both Normal and Standby Modes) |
| Projection Lens |
F=2.6-2.81, f="26.9-29.8mm," 1.15x Manual Zoom and Focus |
| User Controls |
Complete On-Screen Menu Adjustments in 23 Languages |
| I/O Connectors |
HDMI, Two VGA-In, VGA-Out, DVI-D, S-Video, Composite Video, Stereo RCA Audio-In, Stereo Audio-In, Stereo Audio-Out, RS-232, USB, RJ45 and 12V trigger. |
| Security |
Kensington Lock Port and eypad Lock |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Keystone Correction |
±30 deg. Vertical |
| Horizontal Scan Rate |
15, 31 - 90 KHz |
| Vertical Refresh Rate |
50 - 85 Hz |
| Operating Temperature |
41 to 104 deg.F (5 to 40 deg.C), 85% Max Humidity |
| Power Supply |
AC Input 100-240V, 50-60Hz, Auto-Switching |
| Power Consumption |
360 Watts (Bright), 290 Watts (STD), <1 Watt (Standby) |
| Dimensions (W x H x D) |
12.8" x 4.29" x 10.19" (326 x 109 x 259 mm) |
| Weight |
7.8 lbs (3.53kg) |
