| Image Device |
3x 1/3-type progressive 2.2 Mp CMOS Prism color separation |
| Lens |
22x optical zoom - 2x, 5x, 10x digital zoom - 3.9-86mm (28-616mm 35mm equivalent) - f/1.6-3.2 - 18 elements in 12 groups |
| Minimum Object Distance (M.O.D.) |
Approx. 3.3' (1 m) |
| Filter Diameter |
72mm |
| Minimum Illumination |
0.4 lux (f/1.6, gain +30 dB, shutter speed 1/30 second) |
| Signal System |
NTSC |
| Built-in Filters |
ND filter: OFF, 1/4, 1/16, 1/64 |
| LCD Monitor |
3.45" (87.63mm) color LCD monitor with approx. 921K dots (16:9) |
| Viewfinder |
0.45" (11.43mm) color LCoS monitor with approx. 1226K dots (16:9) |
| Memory Card Slot |
2x SD/SDHC/SDXC slots |
| Shutter Speed Preset |
50i/50p: 1/50s (OFF), 1/60s 1/120s, 1/250s, 1/500s, 1/1000s, 1/2000s 25p: 1/25s, 1/50 (OFF), 1/60s, 1/120s, 1/250s, 1/500s, 1/1000s, 1/2000s 60i/60p: 1/60s (OFF), 1/100s, 1/120s, 1/250s, 1/500s, 1/1000s, 1/2000s 30p: 1/30s, 1/50s (OFF), 1/60s, 1/120s, 1/250s, 1/500s, 1/1000s, 1/2000s 24p: 1/24s, 1/50s (OFF), 1/60s, 1/120s, 1/250s, 1/500s, 1/1000s, 1/2000s |
| Shutter Speed Synchro Scan |
SYNC SCAN TYPE = sec. 50i/50p mode: 1/50.0 sec. to 1/250.0 sec. 25p mode: 1/25.0 sec. to 1/250.0 sec. 60i/60p mode: 1/60.0 sec. to 1/249.8 sec. 30p mode: 1/30.0 sec. to 1/249.8 sec. 24p mode: 1/24.0 sec. to 1/249.8 sec. SYNC SCAN TYPE = deg. All mode: 3.0 deg. to 360.0 deg. (by 0.5 degree step selectable) (default = 180.0 deg.) |
| Shutter Speed Slow |
Slow: (VFR on SCENE FILE need to be "OFF".) 50i/50p mode: 1/6 sec., 1/12 sec. and 1/25 sec. 25p mode: 1/6 sec. and 1/12 sec. 60i/60p mode: 1/8 sec., 1/15 sec. and 1/30 sec. 30p mode: 1/8 sec. and 1/15 sec. 24p mode: 1/6 sec. and 1/12 sec. |
| Slow Shutter |
60i mode: 1/8, 1/15, 1/30 second - 30p mode: 1/8, 1/15 second - 24p mode: 1/6, 1/12 second |
| File Format |
AVCHD: MPEG-4 AVC / H.264 DV: AVI Type2 |
| Recording Media AVCHD |
SD memory card: 512MB, 1GB, 2GB (FAT12, FAT16) SDHC memory card: 4GB, 6GB, 8GB, 12GB, 16GB, 32GB (FAT32) SDXC memory card: 48GB, 64GB, up to 2TB (exFAT) Note: *PH/HA mode requires Class4 or faster Card / VFR recording requires Class6 or faster |
| Recording Media DV |
30, 60 fps SD memory card: 512MB, 1GB, 2GB (FAT12, FAT16) SDHC memory card: 4GB, 8GB, 16GB, 32GB (FAT32) SDXC memory card: 8GB, 64GB, up to 2TB (exFAT) Note: DV recording requires Class6 or faster |
| Recording Video Format |
AVCHD: 50 Hz mode: PH mode: 1080/60p, 1080/50i, 1080/25p (over 50i), 720/50p and 720/25p (over 50p) HA, HE mode: 1080/50i only PM mode: 720/50p 59.94 Hz mode: PH mode: 1080/59.94i, 1080/29.97p (over 59.94i), 1080/23.98p, 720/59.94p, 720/29.97p (over 59.94p), and 720/23.98p HA, HE mode: 1080/59.94i only PM mode: 720/59.94p |
| Transmission Rates |
AVCHD: PH mode: approx. 21 Mbps (VBR, max 24 Mbps) PM mode: approx. 8 Mbps (VBR) HA mode: approx. 17 Mbps (VBR) HE mode: approx. 6 Mbps (VBR) |
| Interval Recording |
AVCHD: tandard (MPEG-4 AVC/H.264), DV standard (AVI Type2) OFF / 1 sec. / 10 sec. / 30 sec. / 1min. / 2 min. Note: Recording mode needs to be set in "PH 1080/25p" or "1080/23.98p" Maximum continuous recording duration is 168 hours (7 days) |
| Frame Rate |
AVCHD: 50 Hz mode: 1080/25p: 2 (0 dB gain fixed, manual focus) / 6 / 9 / 12 / 15 / 18 / 20 / 21 / 22 / 23 / 24 / 25 / 26 / 27 / 28 / 30 / 32 / 34 / 37 / 42 / 45 / 48 / 50 fps 59.94 Hz mode: 1080/23.98p or 1080/29.97p: 2 (0 dB gain fixed, manual focus) / 6 / 9 / 12 / 15 / 18 / 20 / 21 / 22 / 24 / 25 / 26 / 27 / 28 / 30 / 32 / 34 / 36 / 40 / 44 / 48 / 54 / 60 fps |
| Video Out |
AVCHD: SDI x1, .8Vp-p, 75 O, HD/SD auto-detect, but none-converting between HD/SD HDMI x1, type A (1080i / 720p) Pin jack x 1, 1.0Vp-p, 75 O, 480/60i (59.94Hz) or 576/50i (50Hz)
DV: SDI x1, 480/60i (59.94Hz) or 576/50i (50Hz) Pin jack x1, 1.0Vp-p, 75 O, 480/60i (59.94Hz) or 576/50i (50Hz) FireWire IEEE 1394 6-pin x1 |
| Audio Compression |
AVCHD: PH mode: Dolby Digital/2ch, linear PCM switchable PM/HA/HE mode: Dolby Digital/2ch
DV: Linear PCM (Digital 2ch) |
| Audio Sampling Frequency |
AVCHD / DV: 48 kHz |
| Audio Quantization |
AVCHD / DV: 16 bit |
| Audio Bit Rate |
AVCHD: PH mode: 384kbps PM/HA/HE mode: 256kbps |
| Built-In Microphone |
Stereo microphone |
| Audio In |
3-pin XLR x2 (Input 1, Input 2) Line / Mic switchable, high-impedance Line: 0 dBu Mic: -40 / -50 / -60 dBu (selectable in menu) Mic Power: +48V ON/OFF switchable Headphone: 3.5 mm stereo mini jack x1 Headroom 12dB |
| Audio Out |
Pin jack x2 (ch 1, ch 2), output: 316 mV, 600O ohm SDI: 2 ch (linear PCM) HDMI: 2 ch (linear PCM) 5.1ch (Dolby Digital) |
| Built-in Speaker |
Round built-in speaker: .78" (2 cm) x1 |
| Remote |
Camera remote: 2.5 mm super mini jack x1 for ZOOM and recording START/STOP 3.5 mm mini jack x1 for FOCUS and IRIS controls
INDEX remote: 2.5 mm super mini jack x1 |
| TC Preset |
In: 1.0 to 4.0 Vp-p, 10 kO Out: 2.0±0.5 Vp-p, low impedance
They double as video out |
| USB 2.0 |
Mini B type connector |
| LCD Monitor |
3.45" LCD color monitor (8.76 cm) Approx. 921,000 pixels (16:9) |
| Viewfinder |
.45 inches, LCD color viewfinder (1.14 cm) Approx. 1,226,000 pixels (16:9) |
| Power Requirements |
7.2V DC via battery 7.3V DC via AC adapter |
| Power Consumption |
11.8W when recording |
| Operating Temperature |
0 to 40 Deg.C (32 to 104 Deg.F) |
| Operating Humidity |
10-80% (no condensation) |
| Dimensions (W x H x D) |
7 x 7.69 x 17.25" (180 x 195 x 438mm) excluding protrusions |
| Weight |
5.3 lb (2.4 kg) Camcorder main body only |
