Peerless PRS-1W Low-Profile Projector Ceiling Tilt Mount, Supports up to 25 lbs (11.3kg), Roll and Pitch Adjustments, White

Peerless
SKU: PEEPRSS1W MFR: PRSS-1W
Peerless PRS-1W Low-Profile Projector Ceiling Tilt Mount, Supports up to 25 lbs (11.3kg), Roll and Pitch Adjustments, White

See all shipping options

Drop Ship This item is typically shipped to you directly from Manufacturer within 2-5 Days. Delivery is subject to availability. learn more

Our Price

$49.95
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About Peerless PRS-1W

The Peerless PRS-1W Low-Profile Projector Ceiling Tilt Mount (White) combines unsurpassed durability and versatility, with the ability to support and securely mount virtually any projector up to 25 lbs (11.3kg) anywhere on a ceiling surface. Designed and built with both professional visual presentation pundits and home theater enthusiasts in mind, this mount offers exceptional design and strength in a simple form factor and offers a very shallow mounting depth of 2.2".

This mount enables projector-to-screen registration with 360deg. rotation (with optional extension column), 30deg. swivel (flush mounted), independent ±10deg. roll and +5deg./-20deg. pitch/tilt adjustments. It features a beefy aluminum alloy construction, fine tuning adjustments, Armor Lock security and cable management - integrates easily with a slew of Peerless' ceiling mount accessories, couples to standard 1.5" NPT steel pipe, ships pre-assembled and includes mounting hardware for both wood or concrete surfaces.

Peerless PRS-1W Features

  • Mount ships completely pre-assembled
  • Quick-release for easy projector removal and maintenance
  • Pitch: +5deg./ -20deg., Roll: ± 10deg., Swivel: 360deg. with extension column
  • (30deg. swivel when flush mounted)
  • Easy cord management via access opening
  • Comes with hardware for installation to wood joist or concrete
  • Secured with Armor Lock at every connection point
  • Works with Spider Universal Adapter plate, model-specific adapter plates or universal clamp-style adapter plates

Peerless PRS-1W Specifications

Construction
Aluminum Alloy
Requirements
Optional Projector Adapter Plate
Finish
Scratch Resistant Fused Epoxy
Depth From Mounting Source
2.2" (55.8mm)
Adjustments
Roll:
±10deg.
Pitch:
+5deg./-20deg.
Yaw:
360deg. with extension column
30deg. swivel when flush mounted
Coupling
1.5" (38.1mm) NPT
Load Capacity
25lbs (11.33kg)
Dimensions (LxWxH)
Base Mount: 4.63x4.63x2.22" (117.60x117.60x56.38mm)
Weight
1.20lbs (0.54kg)
