| Format |
DVD-Video (Video, VR), Video-CD and CD-DA |
| Disc Type |
DVD-Video (NTSC/PAL), DVD-R/RW Video mode (NTSC/PAL), DVD-RW VR mode (NTSC/PAL, CPRM compliant), Dual layer DVD-R Video mode (NTSC/PAL), Video-CD (NTSC/PAL), CD-AUDIO, CD-R, CD-RW |
| Output Level |
DVI-D: NTSC (1080i, 720p, 480p, 480i, VGA), PAL (1080i, 720p, 576p, 576i) |
| Video Output Terminal |
BNC x1, RCA (monitor) x1 |
| S Output ( Y Output Level ) |
1 Vp-p (75 ohms load, synchronous load) |
| S Output ( C Output Level ) |
286 mVp-p (75 ohms load) |
| Y Component Video Output Level |
1 Vp-p (75 ohms load) |
| Pb Component Video Output Level |
0.64 Vp-p (75 ohms load, NTSC with Black Set up) |
| Pr Component Video Output Level |
0.64 Vp-p (75 ohms load, NTSC with Black Set up) |
| Signal to Noise Ratio |
73 dB or more |
| Horizontal Resolution |
540 lines or more |
| Input Level |
Black Burst - 0.3 Vp-p (75 ohms load) BNC x2 (loop-through) |
| Channels |
2 channels (Left, Right) |
| Digital Audio Specifications |
AC-3, PCM, MPEG, DTS (RCA x1, Optical x1) |
| Frequency Response |
4 Hz - 44 kHz (DVD fs : 96 kHz), 4 Hz - 20 kHz (CD fs : 44.1 kHz) |
| Signal to Noise Ratio |
118 dB |
| Dynamic Range |
98 dB |
| Communication Interface |
RS-232C Communication: D-sub 15-pin Female x1, D-sub 9-pin Male x1 |
| RS-232C Serial I/F |
Baud rate 4800/9600/19200 bps (Default Setting: 4800 bps) |
| External Sync Lock |
Black Burst |
| Operating Humidity |
5% to 85% (no condensation) |
| Safety Standards |
Safety: UL, FDA
Radiation: FCC Class B |
| Power Requirement |
AC 120 V, 50 Hz / 60 Hz |
| Power Consumption |
23 W (Playback), 0.8 W (Standby) |
| Dimensions |
16-9/16" x 3-3/8" x 12-3/16"
420 x 86.2 x 309.2 mm |
| Weight |
11 lbs. 11 oz., 5.3 kg |
