| Flash Power |
7.8 to 250 watt-seconds |
| Guide Number (ISO100@10ft.) |
130 w/PL7R reflector at full power |
| Flash Duration |
1/2000 second at full power; 1/640 second at 1/32 power |
| Recycle Time |
1.25 sec. at full power; 0.25 sec. at 1/32 power |
| Power Control |
Range: Full to 1/32 power (6 f-stops); 0.1 f-stop resolution |
| Modeling Light Power |
250 watt Quartz, ESS |
| Modeling Light Control |
Range: Full to 1/32 power (6 f-stops); 0.1 f-stop resolution |
| Triggering |
Sync jack (5 volts); Push-to-test button; Built-in photo slave |
| Sync Voltage |
5V isolated |
| Main Supply |
105 - 125 VAC, 60 Hz, 10 Amps |
| Consumption |
0.2 Amps idling, 15 Amps charging |
| Voltage Stabilization |
± 0.05 f-stop |
| Overload Protection: |
Fuse: 3AG type 16 amp, SLO-BLO |
| Housing |
Extruded aluminum |
| Dimensions (housing only) |
4.5" x 4.5" x 6.75" / 11.43 x 11.43 x 17.15 cm |
| Weight |
4 lbs. 10 oz. / 1.81 kg. 283 g. |
