| Capacity |
2.0 TB (4 x 500 GB) |
| Array Type |
External RAID |
| Bays |
4 |
| Drive Types Supported |
2.5" (6.35 cm) SATA hard disk drives and solid state drives |
| Channels |
4: 2x per Thunderbolt port |
| Sustained Data Transfer Rate |
Up to 480 MB/s with 7200rpm HDDs Over 750 MB/s with SSDs |
| Video Stream Playback |
PCI Express (PCIe) expansion bus protocol integrated with DisplayPort protocol for simultaneous data transmission and video output |
| RAID |
RAID 0, 1 and JBOD Combinations possible via daisy chaining |
| Desktop/Rackmount |
Desktop |
| Status Indicator |
HDD LED and Thunderbolt connections LED |
| Input and Output Connectors |
2x Thunderbolt 10 Gb/s interfaces (cables sold separately) |
| Fan |
Yes, located on bottom of unit |
| Security |
No |
| System Requirements |
Mac computer with OS X 10.6.8, 10.7.4, 10.7.5, 10.8 or 10.8.2 and Thunderbolt port: MacBook Pro 13", MacBook Pro 15", MacBook Pro 17", iMac 21", iMac 27", MacBook Air, or Mac mini Display monitor: Apple LED Thunderbolt, Apple LED Cinema, Dell UltraSharp U3011, Philips 273P3LPHEB/96 Not Windows compatible |
| Supported Drives-1 |
SATA hard drives: Hitachi 750GB Travelstar 7K750 (model #HTS727575A9E364) with 0D0 firmware Seagate 250GB Momentus Thin (model #ST9250LT003) with 0001SDM1 firmware, 500GB Momentus XT (model #ST95005620AS) with SD26 firmware and 750GB Momentus (model #ST9750420AS) with 0001SDM5 firmware |
| Supported Drives-2 |
Toshiba 750GB MQ01ABD (model #MQ01ABD075) with 1U firmware and 500GB MQ01ABD (model #MQ01ABD050) with 01A firmware SSD drives: Toshiba 240GB THNSNS Series (model #THNSNS240GBSP) with TPCABBF0 firmware Intel 240GB 520 Series (model #SSDSC2CW2400A3) with 400i firmware, 120GB 510 Series (model #SSDSC2MH120A2) with PPG4 firmware and 300GB 320 Series (model #SSDSA2BW300G3) with 4PC10302 firmware Samsung 256GB 830 series (model #MZ--7PC256) with 2B1Q firmware |
| Electrical Requirements |
Power adapter (included) |
| Construction |
Aluminum |
| Weight |
With HDDs: 5.29lbs (2.4kg) Without HDDs: 3.53lbs (1.6kg) |
