| System Requirements: Windows |
Windows 7, Vista, XP (32-bit and 64-bit)
Intel Pentium 4 1.6 GHz processor or AMD Athlon 64 (Turion) (2.5 GHz or faster recommended)
1 GB RAM (2 GB or more recommended) |
| System Requirements: Macintosh |
Mac OS X 10.5.2 or later (32-bit and 64-bit)
PowerPC G4 1.25 GHz or Intel Core Solo 1.5 GHz processor (2 GHz or faster recommended)
1 GB RAM (2 GB or more recommended) |
| System Requirements Other |
IEEE 1394 FireWire 400 Port
Internet connection recommended
DVD-ROM drive
Internal or external 7200 RPM storage drive highly recommended |
| Microphone Preamp Type |
XLR Female, Balanced |
| Mic Preamp: Response to Direct Output |
20 Hz-40 kHz, 0 / -0.5 dBu (at unity gain) |
| Mic Preamp: Response to Main Output |
20 Hz-20 kHz, ± 0.5 dBu (at unity gain) |
| Mic Preamp: Input Impedance (Balanced) |
1 kohms |
| Mic Preamp: THD to Direct Output |
< 0.005%, +4 dBu, 20 Hz-20 kHz, unity gain, unwtd (1 kHz at unity gain) |
| Mic Preamp: THD to Main Output |
0.005%, +4 dBu, 20 Hz-20 kHz, unity gain, unwtd (1 kHz at unity gain) |
| Mic Preamp: EIN to Direct Output |
+125 dB unwtd, +130 dB A-wtd |
| Mic Preamp: S/N Ratio to Direct Output |
-97 dB (Ref = +4 dB, 20 kHz BW, unity gain, A-wtd) |
| Mic Preamp: S/N Ratio to Main Output |
-94 dB (Ref = +4 dB, 20 kHz BW, unity gain, A-wtd) |
| Mic Preamp: Common Mode Rejection Ratio |
+65 dB (1 kHz at unity gain) |
| Mic Preamp: Gain Control Range (± 1 dB) |
-16 dB to +67 dB |
| Mic Preamp: Maximum Input Level |
+16 dBu (unity gain) |
| Mic Preamp: Phantom Power (± 2 VDC) |
+48 VDC |
| Line Inputs, Balanced Type |
1/4" TRS Female, balanced mono |
| Balanced: Response to Direct Outputs |
10 Hz-40 kHz, 0 / -0.5 dBu (at unity gain) |
| Balanced: Response to Main Outputs |
20 Hz-20 kHz, 0/-0.5 dBu(at unity gain) |
| Line Inputs, Balanced: Input Impedance |
10 kohms |
| Balanced: THD to Direct Output |
<0.0007%, +4 dBu, 20 Hz-20 kHz, unity gain, unwtd (1 kHz at unity gain) |
| Balanced: THD to Main Output |
<0.005%, +4 dBu, 20 Hz-20 kHz, unity gain, unwtd (1 kHz at unity gain) |
| Balanced: S/N Ratio to Direct Output |
-105 dB (Ref = +4 dBu, 20 kHz BW, unity gain, A-wtd) |
| Balanced: S/N Ratio to Main Output |
-94 dB (Ref = +4 dBu, 20 kHz BW, unity gain, A-wtd) |
| Balanced: Gain Control Range (± 1 dB) |
-20 dB to +20 dB |
| Balanced: Maximum Input level |
+22 dBu (unity gain) |
| Line Inputs, Unbalanced: Type |
RCA Female, unbalanced (stereo pair) |
| Line Inputs, Unbalanced: Max Input Level |
+22 dBu |
| Main Outputs Type |
XLR Male, balanced (stereo pair); 1/4" TRS Female, balanced (stereo pair) |
| Main Outputs: Rated Output Level |
+24 dBu |
| Main Outputs: Output Impedance |
10 kohms |
| Aux Outputs: Type |
1/4" TRS Female, balanced (mono) |
| Aux Outputs: Rated Output Level |
+18 dBu |
| Aux Outputs: Output Impedance |
51 ohms |
| Monitor Outputs Type |
1/4" TRS Female, balanced (stereo pair) |
| Monitor Outputs: Rated Output Level |
+18 dBu |
| Monitor Outputs: Output Impedance |
51 ohms |
| System Cross Talk |
Input to Output (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)-90 dBu
Adjacent Channels (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)-87 dBu |
| Noise Gate (Expander): Threshold Range |
-84 dB to 0 dB |
| Noise Gate (Expander): Attack Time |
Adaptive (0.2 - 2.5 ms) |
| Noise Gate (Expander): Release Time |
70 ms |
| Noise Gate: Expander Attenuation Range |
2:1 (Expander) |
| Compressor: Threshold Range |
-56 dB to 0 dB |
| Compressor: Ratio |
1:1 to 14:1 |
| Compressor: Response Time |
0.2 ms / 1.0 s ("Tight") to 180 ms/1.0 s ("Smooth")(Attack/Release) |
| Compressor: Auto Attack and Release |
Attack = 10 ms, Release = 150 ms |
| Compressor: Curve Types |
Hard and soft knee |
| EQ Type |
2nd - order shelving filter (Q = 0.55) |
| EQ: Low (Low-pass or Bandpass) |
36 to 465 Hz, ± 15 dB |
| EQ: Mid |
26 Hz to 3.5 kHz, ±15 dB |
| EQ: High (High-pass or Bandpass) |
1.4 kHz to 18 kHz, ±15 dB |
| Digital Audio: ADC Dynamic Range |
118 dB (A-wtd, 48 kHz) |
| Digital Audio: DAC Dynamic Range |
118 dB (A-wtd, 48 kHz) |
| Digital Audio: FireWire |
S400, 400 Mb/s |
| Digital Audio: Internal Processing |
32-bit, floating point |
| Digital Audio: Sampling Rate |
44.1, 48 kHz |
| Digital Audio: A/D/A Bit Depth |
24 bits |
| Digital Audio: Reference Level |
-18 dBu |
| Clock: Jitter |
<20 ps RMS (20 Hz - 20 kHz) |
| Clock: Jitter Attenuation |
>60 dB (1 ns in = 1 ps out) |
| Power: Connector |
IEC |
| Power: Input-Voltage Range |
90 to 240 VAC (factory-configured for country of destination) |
| Power: Power Requirements (continuous) |
100 W |
| Dimensions (L x W x H) |
15.56" x 16" x 5.5" / 397 x 106 x 140 mm |
| Weight |
20 lbs / 9.07 kg |
