Rode PinMic-Long Wearable Microphone, 60Hz to 18kHz Frequency Range, 3000 ohm Output Impedance

SKU: RDPML MFR: PINMIC-LONG
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

Our Price

$249.00
Free Shipping
Qty:

Add to Wishlist

Protect your investment

About the Rode Microphones PinMic Microphone

The Rode PinMic is a discreet lavalier/lapel microphone with an innovative pin-through design that is not only easier to conceal than a traditional lapel microphone, but provides greater mounting versatility. It comprised of a cabled back plate and a removable omni-directional capsule head. The PinMic is easily mounted onto any clothing or fabric by simply pushing the back plate pins through the back of the fabric and sliding the capsule into place on the front.

The microphone back plate and cable are hidden behind the fabric and the capsule head can be easily disguised, covered or decorated to further conceal the microphone. The PinMic capsule is discrete at only 9mm deep and 11mm in diameter. The microphone easily mounts through any fabric 1.5-3.5mm (0.006-0.14") thick without any damage to clothing. The regular PinMic is available for mounting on standard fabrics (up to 1.5mm/0.006" thick).

The microphone capsule is connected via a 1.2m (4') shielded, detachable Kevlar reinforced cable that has been rigorously strain tested to ensure reliable performance. The included mini-furry for high wind protection ensures quality recordings in adverse environments, while the anti-trauma water resistant case provides rugged and secure protection for the microphone, a spare capsule head, the microphone cable and included accessories.

The PinMic is an ideal solution for film, television, video, theatre, house of worship and anywhere where a high quality microphone needs to be heard but not seen. Knowing that versatility is paramount in any product, Rode has developed the MiCon Connector System which provides seamless integration between the PinMic and a wide range of wireless systems as well as consoles, cameras and portable recorders.

Rode Microphones PinMic Microphone Includes

  • Rode PinMic-Long Wearable Microphone
  • Impact Resistant Storage Case
  • Water Resistant Pop Filter
  • Mini-Furry
  • Shielded Detachable Kevlar Reinforced Cable
  • Lapel Style Cable Management Clip
  • Adjustment Tools
  • Rode 1 Year Warranty

Rode Microphones PinMic Microphone Specifications

Acoustic Principle Pressure Gradient
Active Electronics JFET impedance converter
Capsule 0.10" / 0.25cm
Polar Pattern Omnidirectional
Address Type End
Frequency Range 60Hz - 18kHz
Output Impedance 3000 ohm
Maximum SPL 110dB SPL (@ 1kHz, 1% THD into 1KO load)
Maximum Output Level 189.0mV (@ 1kHz, 1% THD into 1KO load)
Sensitivity -33.5dB re 1 Volt/Pascal (21.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
Power Requirements Min 2V - Max 5V through MiCon wireless adaptors
P48 through MiCon XLR adaptor
Output Connectors MiCon XLR Adaptor
Dimensions (H x W x D) 0.72 x 0.86 x 1.29" (18.50 x 22 x 33mm)
Weight 0.35oz (10g)
