| Rated Output power |
2 X 500W at 4ohms@ 0.1% THD at 1KHz, 1 X 1000W at 8ohms Bridged |
| Frequency response |
20Hz-20KHz+/-0.7dB@1W Output into 8ohms (AMP OUT) 20 Hz-20KHz+/-0.4@+4dB Output into 10kohms (Main OUT, Main OUT 2, AUX OUT, AUX SEND, EFX OUT) |
| Total Harmonic Distortion |
Less than 0.06% @ 20Hz- 20KHz, 75W output into 4ohms (SPEAKER OUT); Less than 0.1%@20 Hz-20KHz+4dBu output into 10Kohms (Main OUT, Main OUT 2, AUX OUT, EFX OUT) |
| HUM & Noise |
-121dB equivalent input noise
Average, RS+150ohms: -100dB residual output noise (Main OUT, AUX OUT, EFX OUT)
With 22Hz-22KHz BPF:
-79dB (Main OUT, AUX OUT) Master level control at maximum, all channel level control at minimum
-79dB (EFX OUT) Master level control at maximum, all channel level controls at minimum |
| Maximum Voltage Gain |
67dB CH IN (MIC) to AMP OUT
63dB CH IN (MIC) to MAIN OUT, Monitor OUT
54dB CH IN (MIC) to AUX 2 OUT
30dB CH IN (MIC) to REC OUT
32dB CH IN (LINE) to Main OUT, Monitor OUT
26dB AUX IN to Main OUT
24dB TAPE IN to Main OUT |
| Crosstalk 1KHz |
70dB adjacent input, 70dB input to output |
| Input Channel Equalization |
High: 12KHz shelving (+/- 15dB MAX)
Mid: Variable 100 Hz to 8kHz peaking (+/- 15dB MAX)
Low: 80Hz shelving (+/- 15dB MAX) |
| Meters |
11 Point LED Meters (-20, -15, -10, -7, -5,-3, 0, +1, +2, +4, +6dB) |
| Graphic Equalizer |
9 bands (63, 125, 250, 500, 1K, 2K, 4K, 8K, 16KHz) |
| Internal DSP Effects |
24 Bit - 10 Presets each: 1- Performance; 2-Hall Reverb, 3-Plate Reverb; 4 -Spring Reverb; 5-Echo; 6-Flange + Verb; 7-Chorus + Verb; 8-Echo + Verb; 9-Chorus; 10-Flange |
| Phantom Power |
+48V |
| CLIP Indicators |
Turn on: THD> 0.1% |
| Foot Switch |
Digital Effect Mute: ON/OFF |
| Power Consumption |
1900W, max |
| Dimensions (W x H x D) |
24-1/2" x 6-1/4" x 21" /622mm x 159mm x 533mm |
| Weight |
50.6 lbs./23Kg |
