Sturdy metal housing (transmitter and receiver) |
|
42 MHz bandwidth: 1680 tunable UHF frequencies for interference-free reception |
|
Enhanced frequency bank system with up to 24 compatible frequencies |
|
Ethernet port for connecting to the Wireless Systems Manager (WSM) software for control via computer - this delivers a good overview of monitoring and professional data management for multi-channel systems |
|
High-quality true diversity reception |
|
Pilot tone squelch for eliminating RF interference when transmitter is turned off |
|
Automatic frequency scan feature searches for available frequencies |
|
Enhanced AF frequency range |
|
Increased range for audio sensitivity |
|
Wireless synchronization of transmitter parameter from receiver |
|
User-friendly menu operation with more control options |
|
Illuminated graphic display, receiver also shows transmitter settings |
|
Auto-Lock function avoids accidental changing of settings |
|
HDX commander for crystal-clear sound |
|
Transmitter feature battery indicatation in 4 steps, also shown on receiver display |
|
Programmable Mute function |
|
Integrated Equalizer and Soundcheck mode |
|
Contacts for recharging BA 2015 accupack directly in the transmitter |
|
Wide range of accessories adapts the system to any requirement |
| Receiver principle | True Diversity |
| Receiver: Sensitivity | <2 µV at 52 dBAeff S/N (with HDX, peak deviation) |
| Receiver: Adjacent channel rejection | = 75 dB |
| Receiver: Intermodulation attenuation | = 70 dB |
| Receiver: Blocking | = 75 dB |
| Receiver: Pilot-tone squelch | Detachable |
| Receiver: Antenna inputs | 4 BNC sockets |
| Receiver: AF output voltage | 1/4" (6.3 mm) jack socket, unbalanced: +12 dBu XLR socket, balanced: +18 dBu (at peak deviation, 1kHz AF) |
| Receiver: Power supply | 12 V DC |
| Transmitter: RF output power at 50 ohm | typ. 30/10 mW, switchable |
| Transmitter: AF frequency response | 25 - 18.000 Hz (Line)
80 - 18.000 Hz (Mic) |
| Max input voltage transmitter / line | 3 Veff |
| Input impedance transmitter / line | 40 kO, unbalanced / 1 MO |
| Transmitter: Power supply | 2 AA batteries, 1.5 V |
| Transmitter: Nominal voltage | 2.4 V |
| Transmitter: Operating time | typ. 8h |
| Transmitter: Dimensions | 82 x 64 x 24 mm / 3.23" x 2.52" x 0.94" |
| Receiver: Dimensions | 202 x 212 x 43 mm (7.95" x 8.35" x 1.69") |
| Receiver: Weight | approx. 980 g (2.16 lbs) |
| Weight | approx. 160 g (5.64 oz) |
| Warranty | Sennheiser 2 years limited warranty |
| | |
