Sennheiser XSW 72 Instrument Set Wireless Instrument Microphone System, 548-572 MHz Frequency

Sennheiser XSW 72: Picture 1 thumbnail Sennheiser XSW 72: Picture 2 thumbnail

List Price: $379.00

Free Shipping

See all shipping options

In Stock Online - Usually ships within 1-2 Days learn more

Protect Your Investment:

Add a Protection Plan
  • Add a protection plan
  • New Leaf 3 Year Extended Warranty + $24.95
  • New Leaf 3 Year Drops & Spills Extra Protection + $39.95
  • New Leaf 5 Year Drops & Spills Extra Protection + $84.95
21% Off

Our Price

Buy more and save
Quantity Discount

The quantity discount will be reflected in your shopping cart

About Sennheiser XSW 72

The Sennheiser XSW 72 Instrument Set Wireless Instrument Microphone System (548-572 MHz frequency) delivers sound quality and performance in an affordable, easy to use package designed to keep musicians cable-free on stage. The XSW 72 Instrument Set features a true diversity receiver and bodypack transmitter with a 1/4" phone instrument cable for connecting guitars and other instruments.

The system operates on the 24 MHz UHF frequency band and features 960 tunable frequencies, 8 frequency banks and 12 coordinated channels per bank. True diversity reception greatly minimizes noise, interference and artifacts. Both the transmitter and receiver are capable of remote channel sync and the transmitter will operate for up to 10 hours on 2 AA batteries.

Sennheiser XSW 72 Features

  • True Diversity reception for worry-free operation
  • 24MHz switching bandwidth
  • 960 available frequencies, tunable in 25kHz steps
  • 8 frequency banks containing 12 coordinated channels each
  • Powerful scan function identifies available channels within a bank
  • Component synchronization at a distance with new "Remote Channel" sync
  • Up to 10 hours of operation with (2) AA batteries
  • Up to 250 feet of transmission range
  • Illuminated audio mute button on transmitters
  • Balanced (XLR) and unbalanced (1/4") outputs

Sennheiser XSW 72 Specifications

True diversity
Wideband FM
< 3 uV at 52dBarms S/N (at peak deviation)
Frequency Range
548 - 572MHz
Switching Bandwidth
Adjacent Channel Crosstalk
= 60dB
Intermodulation Distortion
Intermodulation rejection = 50dB
960, tunable in 25kHz steps
Frequency presets: 8 frequency banks, each with 12 coordinated factory-preset channels
= 65dB
Frequency Response
Signal-to-Noise Ratio
= 103dBa
= 1%
32 to 104deg. F (0 to +40deg. C)
Antenna Inputs
2 BNC connectors, 50 ohm
Output Voltage
XLR (balanced): +14dBu; 1/4" (unbalanced): +8dBu (at peak dev., 1kHz AF)
Power Supply
12VDC nom. / 300mA
13.39 x 13.58 x 3.35" / 34.01 x 34.49 x 8.50 cm (single)
3.62 lbs / 1.64 kg (single)
