Shure

Shure P9TR-L6 PSM900 Wireless Personal Monitoring System, 656-692 MHz Frequency Range

SKU: SHP9TRL6 MFR: P9TR-L6
Please note! This is a Special Order Item and is Non Cancelable and Non Returnable.
We Charge you when you place your order. Approximate arrival at Adorama 1 - 2 Weeks from date of order.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$1,650.00 List Price

Our Price

$1,099.00 $43 per week
Free Shipping
Qty:
Add to Wishlist

Protect your investment

About the Shure P9TR-L6

The Shure P9TR-L6 PSM900 is a professional-quality wireless monitoring system that provides high-quality audio and RF performance in a compact and durable design. The system consists of a P9T transmitter and a P9R bodypack receiver. The system features an enhanced digital stereo encoder that enhances audio detail and clarity and patented Audio Reference Companding that sounds more like wired audio than other competing wireless systems.

Patent-pending CueMode technology lets you monitor different stage mixes, as well as store up to 20 different channels on a single bodypack receiver. A Scan and Sync function creates an IR link between the components for fast and easy syncing. RF muting provides easy setup without creating RF interference. RF scan and automatic gain features provide excellent RF stability and channel availability and prevent dropout due to RF overload. MixMode technology lets the receiver balance the levels of 2 audio channels while receiving each signal in both ears simultaneously.

The transmitter has a compact half-rack design with XLR/TRS combo inputs, loop outputs and a 3.5 mm headphone jack for monitoring. It also has a backlit LCD display and LED level meters. The receiver has slim aluminum housing with volume and balance controls and a 3.5 mm headphone jack. It has an LCD screen for navigating settings and menus and it operates on a pair of standard AA batteries.

Shure P9TR-L6 Includes

  • Shure P9T Wireless Transmitter for PSM900 (L6: 656-692 MHz)
  • P9R Wireless Stereo Bodypack Receiver for PSM900 (L6: 656-692 MHz)
  • Shure Warranty

Shure P9TR-L6 Features

  • RF Mute Switch allows system setup without causing RF interference
  • Syncs to a P9R bodypack quickly and easily over IR link using Scan and Sync
  • Front panel audio input gain adjustment and LED level meter with clipping indicator
  • Front or back mountable antennas
  • Compatible with PA421A and PA821A antenna combiners
  • Loop out connectors for multiple mix setups and easy installation
  • Switchable +4 dBu and -10 dBV input level
  • Balanced, 1/4" and XLR connectors
  • Bit-mapped, backlit LCD
  • Includes rack-mounting hardware
  • 1/8" headphone out on the front panel for easy monitoring
  • Ultra-thin, low profile bodypack allows discreet placement on the performer
  • Enhanced digital stereo encoder provides an expansive soundstage for excellent audio clarity and detail
  • RF Scan: stand where the artist will be on stage and instantly check RF level
  • Automatic Gain Control greatly prevents signal dropout due to RF overload and allows more channels to be used simultaneously
  • Syncs to a P9T transmitter quickly and easily over IR link using Scan and Sync
  • Switchable 10/50/100 mW output power provides a robust RF link in a variety of performance environments
  • Separate, easily visible audio and RF status indicator LEDs
  • Audio level and battery life metering
  • Selectable high-frequency EQ boost (+3/+6 dB @ 10 kHz)
  • Volume and balance controls
  • Extruded aluminum construction for rugged dependability

Shure P9TR-L6 Specifications

Modulation FM, MPX Stereo
Operating Range 300' (90 m)
Frequencies L6: 656-692MHz
Transmitter: Output Power 10/50/100mW, Selectable (Regionally Dependent)
Transmitter: Output Impedance 50 Ohms (RF, Typical)
Transmitter: Input Level +4dBu and -10dBV, Switchable
Transmitter: Connectors 2 x XLR/TRS Combo Inputs
2 x 1/4" Loop Outputs
1 x DC Power Input
1 x Antenna Connector
1 x 3.5mm Headphone Jack
Transmitter: Power Requirements 415mA, Typical (RF On, 100mW Power Mode, No Audio)
Receiver: Frequency Response 35Hz - 15kHz
Receiver: Signal to Noise Ratio 90dB
Receiver: RF Sensitivity 2.2uV
Receiver: Filter -3dB @ 30.5MHz, Front-End RF Filtering
Receiver: Gain Control 31dB
Receiver: Image Rejection > 100dB
Receiver: Adjacent Channel Crosstalk > 70dB
Receiver: Squelch 22dB SINAD
Receiver: Intermodulation Distortion > 70dB
Receiver: Load Impedance 9.5 Ohms
Receiver: Output Power 10/50/100mW, Selectable
Receiver: Connectors 1 x 3.5mm Headphone Jack
1 x Antenna Connector
Receiver: Battery Type/Life 2 x AA, Approx 5-7 Hours
Dimensions (W x D x H) Transmitter: 7.75 x 6.5 x 1.6" (197 x 166 x 42mm)
Receiver: 2.6 x 0.9 x 3.3" 65 x 22 x 83mm)
Weight Transmitter: 1.9 lbs (0.85kg)
Receiver: 7.05 oz (200g) (With Batteries)
