| Screen Size Class |
70" (69.5" Diagonal) |
| Bezel Width |
39 mm V (left/right) x 35 mm H (top/bottom) |
| Native Display Resolution |
1920 x 1080 |
| Maximum Brightness (average) |
450 cd/m2 |
| Landscape and Portrait Mode Operation |
Yes |
| Certified for 24/7 Continuous Operation |
Yes |
| Fanless Architecture |
Yes |
| Audio |
7W + 7W Stereo with built in speakers |
| LCD Type |
UV2A LCD |
| Number of Colors |
1.06 Billion |
| Contrast Ratio |
4000:1 |
| Aspect Ratio |
16:9 |
| Viewing Angle (H/V) |
176deg. H x 176deg. V (CR>/=10) |
| Active Screen Area |
60-9/16" W x 34-1/16" H |
| Frame Rate |
60 Hz |
| Pixel Pitch |
0.802 mm H x 0.802 mm V |
| Video System |
NTSC (3.58 MHz; 4.43 MHz), PAL, PAL60, SECAM |
| Computer Input - Video |
Analog RGB (0.7 Vp-p) [75-ohm], Digital (conforms to DVI 1.0 standards) |
| Computer Input - Synchronization |
Horizontal / Vertical separation (TTL: positive/negative), Sync on green, composite sync (TTL: positive/negative) |
| Computer Input - Plug & Play |
VESA DDC2B |
| Power Management |
VESA DPMS, DVI DMPM |
| Response Time |
6 ms (gray to gray, avg) |
| PC/AV Video Input |
Analog mini D-sub 15-pin. DVI-D 24-pin HDCP Compatible (requires optional PN-ZB01); Analog 5-BNC (requires optional PN-ZB01; analog RGB and component are menu selectable). |
| PC/AV Audio Input |
3.5 mm mini stereo jack |
| Video Input |
Composite Video - BNC (requires optional PN-ZB01) |
| S-Video Input |
5-Pin DIN (requires optional PN-ZB01) |
| Component Video |
BNC (Y, Cb/Pb,Cr/Pr) (requires optional PN-ZB01; component video and analog RGB are menu selectable) |
| HDMI |
Yes - compatible for both PC and AV components |
| Audio (AV) |
RCA pin (L/R) x 2 (requires optional PN-ZB01) |
| Computer Output |
DVI-D 24-pin (HDCP compatible, PC/AV signal; requires optional PN-ZB01) |
| Audio Line Output |
RCA pin (L/R) - selectable fixed or variable line output |
| Speaker Output |
7W + 7W Stereo (6-ohms; requires optional PN-ZB01) |
| LAN Port |
RJ-45 (requires optional PN-ZB01) |
| RS-232C |
D-sub 9-pin |
| Power Output Connector |
Yes - 19V |
| Screen Adjustment |
Auto (Clock, Phase, H-POS/V-POS) / Manual |
| Gain Control |
Auto (Black level, Contrast) / Manual |
| Digital Scaling (expansion) |
Yes (VGA/SVGA/XGA/SXGA -> 1920 x 1080) |
| Digital Scaling (compression) |
1920 x 1200, 1600 x 1200 |
| Main User Adjustments |
Clock, Phase, H-POS/V-POS, Black level, Contrast; Color temp (15 steps preset + 5600K/9300K + User setting); Color mode (Standard/sRGB/Vivid); Gamma (1.8/2.0/2.2/2.4/User setting); Brightness, Volume, Audio (Treble/Bass/Balance), OSD-POS; Picture Adjustment (Tint, Color Intensity) [PC/AV mode]; R/G/B/Y/M/C independent adjustment [AV mode] |
| Real Time Clock Setting |
Yes |
| Scheduling Function |
Yes (time, day of the week) |
| All Reset |
Yes |
| Reset |
Screen/Picture/Audio adjustment setting, etc. |
| Adjustment Lock |
YES (incl. Power button) |
| Daisy Chain (DVI-D) |
Optional (PN-ZB01): max. 5 units (HDCP compliant) |
| Enlarge |
No |
| Frame Width Adjustment |
Yes |
| PinP / PbyP |
Yes (PinP: 12 steps) |
| Power On Delay |
1-60 seconds (with 1 second interval) |
| Audio Input Change |
Yes |
| Picture Flip |
No |
| Self Adjust |
Yes (PC Analog Input) |
| Log Save / Output |
Yes |
| Temperature Control |
Yes |
| Hardware Diagnosis |
Yes |
| Monitor Control Software Support |
Yes |
| Overscan Setting (AV Input) |
Yes |
| Image Size Change Function |
Yes |
| Resolution Change Function (PC analog) |
Yes |
| RS-232C Communication Speed Change |
Yes |
| Conversion of Stereo Audio to Monaural |
Yes |
| Selection of Audio Input per image input |
Yes |
| Power Consumption |
240W Max. (with optional PN-ZB01 attached) |
| Standby Power Consumption |
1.0 W |
| Power Source |
100 - 240V AC, 50/60 Hz |
| Tuner |
No |
| Operating Temperature |
32 - 104deg.F (0 - 40deg.C) |
| Operating Humidity |
20% to 80% RH (no condensation) |
| Storage Temperature |
-4 - 140deg. F (-20 - 60deg. C) |
| Regulatory Approvals |
UL 60950, FCC Class A |
| Mounting Configuration |
VESA (6 points), 200 mm (7-7/8") pitch, M6 screws or VESA (4 points), 200 mm (7-7/8") pitch, M6 screw |
| Dimensions (W x H x D) |
63.59" x 37.28" x 3.94" / 1615.19 x 946.91 x 100.08 mm |
| Weight |
110 lbs / 49.9 kg |
