Shure ULXD4-G50 Single Digital Wireless Receiver with PS41US Power Supply, 1/2 Wave Antenna & Rack Mounting Hardware, G50/470 to 534MHz Frequency

Please note! This is a Special Order Item and is Non Cancelable and Non Returnable.
We Charge you when you place your order. Approximate arrival at Adorama 1 - 2 Weeks from date of order.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$1,094.00 List Price

Our Price

$875.00 $34 per week
Free Shipping
Add to Wishlist

Protect your investment

About the Shure ULXD4-G50

The Shure ULXD4-G50 is a half-rack, networkable wireless receiver for use with ULX-D Digital Wireless Systems. With an expansive set of professional features, including 24-bit/48 kHz digital audio quality, efficient and intelligent RF performance and AES 256-bit encryption, ULX Digital offers uncompromising wireless tailored for professional sound reinforcement.

Shure ULXD4-G50 Includes

  • Shure ULXD4 Single Digital Wireless Receiver
  • Power Supply
  • 2 x 1/2 Wave Antenna
  • 2 x 2' BNC Cable
  • 2 x BNC Bulkead Adapters
  • Rackmount Kit
  • 5' Ethernet Cable
  • 2 x AA Alkaline Batteries
  • Rackmount Bracket (Short)
  • Rackmount Bracket (Long)
  • Link Bar
  • Shure Warranty

Shure ULXD4-G50 Features

  • Predictive switching diversity
  • Intelligent scanning automatically finds and deploys the cleanest frequencies to transmitters over IR sync
  • Interference detection and alerts provided on both the receiver and Wireless Workbench 6
  • Front panel gain adjustment buttons provide up to 60 dB additional gain
  • AES 256-bit encryption-enabled for applications where secure transmission is needed
  • Ethernet networking provides streamlined setup across multiple receivers, Wireless Workbench 6 integration and AMX/Crestron control
  • Support for frequency coordination with the Axient Spectrum Manager
  • Rugged metal chassis
  • Intuitive front panel LCD menu and controls with lockout feature
  • Upgraded LCD with adjustable contrast and brightness
  • Audio and RF LED meters with peak indicator
  • Remoteable 1/2 wave antennas
  • Furnished rack hardware

Shure ULXD4-G50 Specifications

RF Carrier Frequency G50/470 to 534MHz
RF Input: Spurious Rejection >80 dB, typical
RF Input: Connector Type BNC
RF Input: Impedance 50 Ohms
RF Input: Bias Voltage 12-13 V DC, 170 mA maximum, per antenna
Audio Output: Gain Adjustment Range -18 to +42 dB in 1 dB steps (plus Mute setting)
Audio Output: Configuration 1/4" (6.35 mm): Impedance balanced (Tip=audio, Ring=no audio, Sleeve=ground)
XLR: Balanced (1=ground, 2=audio +, 3=audio -)
Audio Output: Impedance 1/4" (6.35 mm): 100 Ohms (50 Ohms Unbalanced)
XLR: 100 Ohms
Audio Output: Full Scale Output 1/4" (6.35 mm): +12 dBV
XLR: LINE setting= +18 dBV, MIC setting= -12 dBV
Audio Output: Mic / Line Switch 30 dB pad
Audio Output: Phantom Power Protection 1/4" (6.35 mm): Yes
XLR: Yes
Networking: Power Over Ethernet (PoE) No, protected
Networking: Network Interface Single Port Ethernet 10 / 100 Mbps
Network Addressing Capability DHCP or Manual IP address
Networking: Maximum Cable Length 328 ft (100 m)
Audio Frequency Response 20 Hz-20 kHz, flat
Dynamic Range 120 dB, extended
Tuning Range Up to 64 MHz
Housing Galvanized steel
Dimensions (H x W x D) 7.75" x 6.75" x 1.65" (197 mm x 171 mm x 42 mm)
Weight 2.0 lbs (0.90 kg) without antennas
