| Magnification |
3x - 18x |
| Objective / Field of View |
50mm / 39.9' (13.3m) @ 3x at 100 yds.(100m), 6.6 (2.2m) @ 18x at 100 yds.(100m). |
| Main (Center) Tube Diameter |
30mm |
| Lens Coatings |
High Light Transmission Optical System |
| Reticle |
Illuminated 4A Reticle |
| Reticle Image Plane (Magnifying) |
Reticle in Second (ocular-side) Focal Plane, Only the Target is Enlarged |
| Twilight Performance |
8.5 - 30.0 (DIN 58388), 90% Light Transmission |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/3-M.O.A., 10mm, Per Click |
| Maximum Adjustment |
Elevation Range: 64.8" @ 100 yards Windage range: 36" @ 100 yards |
| Exit Pupil |
9.5mm - 2.8mm |
| Eye Relief |
3.74", 95mm |
| Parallax Correction Control |
With 3rd Turret: 50 yards - Infinity |
| Diopter Adjustment |
- 3.0 / + 2.0 |
| Material |
Rugged light alloy main tube. |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
15.12", (384.0mm) |
| Mounting Length |
Not Specified |
| Weight |
22.4 oz., 635g. |
| Special Features |
Objective Filter Thread: 52mm. 7.6 to 1.3 degrees real field of view. Ballistic Turrets |
