| Magnification |
5x - 25x |
| Objective / Field of View |
52mm / 21.9' (7.3m) @ 5x at 100 yds.(100m), 4.5' (1.5m) @ 25x at 100 yds.(100m). |
| Main (Center) Tube Diameter |
1" |
| Objective Tube Diameter |
Not Specified |
| Lens Coatings |
High Light Transmission Optical System |
| Reticle |
Plex Reticle |
| Reticle Image Plane (Magnifying) |
Reticle in Second (ocular-side) Focal Plane, Only the Target is Enlarged |
| Twilight Performance |
7.1 - 25.7 (DIN 58388), Transmission 90% |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/4-M.O.A. Per Click |
| Maximum Adjustment |
43.0" Elevation / 25" Windage |
| Exit Pupil |
9.6mm - 2.1mm |
| Eye Relief |
3.74" |
| Parallax Correction Control |
With 3rd Turret: 50 yards - Infinity |
| Diopter Adjustment |
- 3.0 / + 2.0 |
| Material |
Aluminum |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
14.61", (371.0mm) |
| Mounting Length |
5.4", (137.0mm) |
| Weight |
17.5 oz., 495g. |
| Special Features |
Objective Filter Thread: 54mm. |
