| Magnification |
5x - 30x |
| Objective / Field of View |
50mm / 23.7' (7.9m) @ 5x at 100 yds.(100m), 3.9' (1.3m) @ 30x at 100 yds.(100m). |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
Not Specified |
| Lens Coatings |
High Light Transmission Optical System |
| Reticle |
Illuminated BR Reticle |
| Reticle Image Plane (Magnifying) |
Reticle in Second (ocular-side) Focal Plane, Only the Target is Enlarged |
| Twilight Performance |
14.1 - 38.7 (DIN 58388), Transmission 90% |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/3-M.O.A. Per Click |
| Maximum Adjustment |
43.2" Elevation / 25.2" Windage |
| Exit Pupil |
9.5mm - 1.7mm |
| Eye Relief |
3.74" |
| Parallax Correction Control |
With 3rd Turret: 50 yards - Infinity |
| Diopter Adjustment |
- 3.0 / + 2.0 |
| Material |
Aluminum |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
15.55", (395.0mm) |
| Mounting Length |
5.4", (137.0mm) |
| Weight |
21.2 oz., 600g. |
| Special Features |
Objective Filter Thread: 52mm. High Grid Illumination. |
