| Configuration |
Land camera inside of waterproof housing |
| Construction |
Rubber overmolded polycarbonate housing 304-316 series marine grade stainless steel metal hardware |
| Depth Rating |
200' (60 m) |
| Accessory Lens/Filter Mount |
No, snap-on ring designed exclusively for included lens - not threaded, does not accept standard lenses |
| Port |
Optical glass lens port with anti-reflective coating |
| LCD |
Optical grade polycarbonate window |
| Buoyancy |
Positive |
| Controls |
Control buttons for Power, Shutter, Zoom, Mode (video or still image), Playback, Focus, Flash and Menu |
| Image Sensor |
14 MP CCD (1/2.33") |
| Effective Resolution |
14 million pixels |
| Image Resolution |
4288 x 3216 (14 MP) 3264 x 2448 (8 MP) 2304 x 1728 (4 MP) 1600 x 1200(2 MP) 640 x 480 (VGA) |
| Color Depth |
24-bit color (RGB) |
| Image File Formats |
JPEG |
| Video Mode |
AVI (Motion JPEG): HD 720p @ 30 fps 640 x 480 or 320 x 240 |
| Optics: Lens |
Optical zoom lens |
| Optics: Optical Zoom |
5X |
| Optics: Focal Length |
4.7 - 23.5 mm (26 - 130 mm equivalent) |
| Optics: Digital Zoom |
5X |
| Optics: Playback Zoom |
4X |
| Focus Type |
Auto focus |
| Focus Modes |
Auto, AF Tracking, Face Detection, Macro, Super Macro, Infinity |
| Focusing Range |
Normal focus/no zoom: 6.0" (15cm) to infinity Normal focus/5X zoom: 24" (60 cm) to infinity Macro focus: 2.0" (5.0 cm) to infinity Super Macro focus: 1.0" (2.5 cm) to infinity |
| Shooting Angle |
Horizontal field of view / No zoom: Land: 68deg. Underwater: 51deg. |
| Sensitivity |
ISO: Auto, 64, 100, 200, 400, 800, 1600, 3200 |
| Exposure Modes 1 |
6 Underwater modes: Dive mode with UW color correction Snorkel mode with UW color correction Ext Flash Auto mode Ext Light Mode Ext Flash + Light mode Ext Flash Manual mode |
| Exposure Modes 2 |
27 Land modes: Program AE, Auto, Shutter Priority, Aperture Priority, Intelligent Scene, Sports, Smile Detection, Anti-Shake, Panorama, Skin Soften, De-Blemish, Portrait Man, Portrait Lady, Landscape, Sport, Night Portrait, Night Scene, Candlelight, Fireworks, Text, Sunset, Sunrise, Splash Water, Flow water, Snow, Beach, Pets and Natural Green |
| Exposure/Brightness Adjustment |
Auto, Manual (-2 - +2 EV in 1/3 steps) or Ext Flash Manual |
| Shooting Modes |
SPY mode, Single shot, Continuous (3 pics), Continuous Flash, AEB (bracketing), Album Shot, Burst, Pre-Shot, Couple Shot, Burst 30 fps |
| Aperture |
f/2.8(W) - f/7.9(T) |
| Shutter |
Mechanical shutter: 1 to 1/2000 second |
| White Balance |
Land: Auto, Manual, Daylight, Cloudy, Incandescent, Fluorescent 1, Fluorescent 2 Underwater: Ext Flash WB, Blue water less than 25' (8.0 m), Blue water deeper than 25' (8.0 m), Green water less than 25' (8.0 m), Green water deeper than 25' (8.0 m) |
| Built-in Flash |
Auto, Force on, off, Red-eye reduction, Slow sync, Pre flash |
| Flash: Recycle Time |
As fast as 0.3 seconds (Ext Flash mode, flash on, landscape focus) |
| LCD Display |
3" color LTPS TFT LCD |
| Internal Memory |
20 MB |
| Memory Card |
SD or SDHC cards up to 32 GB 16 GB Class6 SDHC recommended |
| Memory: Read/Write Speed |
3.0 MB/s |
| Power Source |
Lithium rechargeable: 3.7 V, 700 mAh Battery life: 200+ pictures, 2+ hours video, 2-tank dive per charge |
| Self Timer |
Self Portrait, 2 second, 10 second delay and 10+2 second (2 pictures) |
| Certification |
CE, ROHS, FCC |
| Interface |
USB 2.0 connector, AV connector, USB AC power adapter |
| Video Out |
NTSC / PAL |
| Audio Out |
Mono, 1x speaker |
| EXIF Format |
EXIF 2.2 |
| System Requirements |
PC: Windows XP, Vista, 7 MAC: OS 10.4 and up |
| Tripod Mount |
Standard 1/4-20 tripod threads |
| Operating Temperature |
Housing: 33 - 110deg. F (0.6 - 43.3 deg. C) |
| Storage Temperature |
-20 - 140deg. F (-28.9 - 60deg. C) |
| Flash: Quantity |
2 |
| Flash: Type |
Strobe |
| Flash: Modes |
Auto Mode - adjusts brightness Variable power adjustment - manually fine-tune brightness 5 pre-flash cancellation settings |
| Flash: Depth Rating |
200' (60 m) |
| Flash: Effective Range |
2.0 - 8.0' (0.6 - 2.4 m) |
| Flash: Power Source |
4x AA batteries (not included) |
| Flash: Number of Flashes |
Approx. 100 flashes with 4 AA batteries |
| Case: Closure |
Zipper |
| Case: Carrying/Transport Options |
Shoulder strap Top carry handle |
| Dimensions (W x H x D) |
Camera: 3.8 x 2.4 x 0.8" (9.7 x 6.1 x 2.0 cm) Housing: 5.3 x 3.7 x 2.8" (13.5 x 9.4 x 7.1 cm) Case: 14 x 12 x 5.0" (35.6 x 30.5 x 12.7 cm) |
| Weight |
Camera: 4.7 oz (0.1 kg) with battery and SD card Housing: 13 oz (0.4 kg) Housing and inner camera: 1.1 lb (0.5 kg) |
