| Image Sensor |
14 mega pixel CCD (1/2.33") |
| Color |
24-bit color (RGB) |
| Image Resolution |
4288x3216(14mp), 3264x2448(8mp), 2304x1728(4mp), 1600x1200(2mp), 640x480 (VGA) |
| File Format |
JPEG |
| Movie Resolution |
HD 720p / 30fps, 640x480 or 320x240 |
| File Format |
AVI (Motion JPEG) |
| Lens |
5X Optical Zoom
Aperture: F2.8(W) - F7.9(T) |
| Focal Length |
4.7mm - 23.5mm
Film equivalent = 26 - 130mm |
| Focus Type |
Auto Focus from 1" (2.5cm) to infinity |
| Focus Modes |
Auto, AF Tracking, Face Detection, Macro, Super Macro, Infinity. |
| Focusing Ranges |
Normal focus/no zoom: 6" (15cm) to infinity
Normal focus/5X zoom: 24" (60cm) to infinity
Macro focus: 2" (5cm) to infinity
Super Macro focus: 1" (2.5cm) to infinity |
| Shooting Angle |
Horizontal field of view / No zoom: Land: 68deg
Underwater: 51deg |
| Zoom |
25X Total zoom
Optical: 5X
Digital: 5X
Playback: 4X |
| Shutter Speed |
Mechanical shutter
1 to 1/2000 second |
| Recycle Time |
As fast as 0.3 seconds (Ext Flash mode, flash on, landscape focus) |
| ISO |
Auto, 64, 100, 200, 400, 800,1600, 3200 |
| Flash |
Auto, Force ON, OFF, Red-Eye reduction, Slow Sync, Pre Flash |
| Scene Modes-1 |
6 Underwater Modes: Dive mode with UW color correction
Snorkel mode with UW color correction
Ext Flash Auto mode for automatic exposure settings when using one or two external flash(es)
Ext Light Mode for automatic exposure settings when using one or two external photo-video light(s)
Ext Flash + Light mode - for automatic exposure settings when using external flash and photo-video light combination |
| Scene Modes-2 |
Ext Flash Manual mode for manual aperture and shutter speed exposure controls when using one or two external flash accessories
27 Land modes: Program AE, Auto, Shutter Priority, Aperture Priority, Intelligent Scene, Sports, Smile Detection, Anti-Shake, Panorama, Skin Soften, De-Blemish, Portrait Man, Portrait Lady, Landscape, Sport, Night Portrait, Night Scene, Candlelight, Fireworks, Text, Sunset, Sunrise, Splash Water, Flow water, Snow, Beach, Pets and Natural Green. |
| Exposure Adjust |
Auto, Manual (-2 - +2 EV in 1/3 steps) or Ext Flash Manual |
| White Balance |
Land: Auto, Manual, Daylight, Cloudy, Incandescent, Fluorescent 1, Fluorescent 2
Underwater: Ext Flash WB, Blue water <25ft/8m, Blue Water > 25ft/8m, Green water <25ft/8m, Green Water >25ft/8m |
| Self-Timer |
Self Portrait, 2 second, 10 second delay and 10+2 second (2 pictures) |
| Shooting Modes |
SPY mode, Single shot, Continuous (3pics), Continuous Flash, AEB (bracketing), Album Shot, Burst, Pre-Shot, Couple Shot, Burst 30fps |
| LCD |
3.0" color LTPS TFT LCD |
| Memory |
Internal: 20MB
External: SD/SDHC card up to 32GB (Recommend 16GB Class6 SDHC card) |
| Read/Write Speed |
3 MB/s |
| Video Output |
Yes (NTSC and PAL support) |
| Audio Output |
Yes (mono, 1x speaker) |
| EXIF Format |
EXIF 2.2 |
| USB |
Version 2.0 |
| Operating Environment |
PC: Windows XP / Vista / 7
MAC: OS 10.4 and up |
| Instruction Manual |
Included printed English manual.
German, French, Spanish, Italian, Dutch languages available on SeaLife website |
| Language Support |
On-Screen Display: English, German, French, Spanish, Italian, Russian, Dutch, Turkish, Portuguese (Brazil), Chinese (T-C and S-C), Korean
Instruction manual: English (printed), German, French, Spanish, Italian, Dutch |
| Connector |
USB connector, AV connector, USB AC power adapter |
| Power |
Battery: Lithium rechargeable battery (3.7v, 700 mAh) |
| Battery Life |
200+ pictures, 2+ hours, 2-tank dive per charge |
| Certification |
CE, ROHS, FCC |
| Depth |
Individually depth tested to 200' (60 m) |
| Buoyancy |
Positive |
| Controls |
Control buttons for Power, Shutter, Zoom, Mode (video or still image), Playback, Focus, Flash, Menu. |
| Operating Temp |
33 degrees F to 110 degrees F |
| Storage Temp |
-20 degrees F to 140 degrees F |
| O-ring |
Silicone |
| Lens Port |
Optical glass lens port with anti-reflective coating
with snap-on ring to adapt accessory lenses |
| LCD |
Optical grade polycarbonate window |
| Tripod Mount |
Standard 1/4-20 tripod threads to adapt accessories |
| Lanyard |
Padded lanyard with swiveled attachment clip |
| Hardware |
304-316 series marine grade stainless steel metal hardware |
| Material |
Rubber overmolded polycarbonate housing |
| Dimensions (H x W x D) |
Housing: 3.7" x " 5.3 x 2.8" inches / 93mm x 135mm x 71mm
Camera: 2.4" x 3.8" x 0.8" /60mm x 97mm x 19mm |
| Weight |
Housing without inner camera: 370 grams (13 ounces)
Housing with inner camera: 504 grams (17.7 ounces)
Camera: 134 grams (4.7 ounces) with battery and SD card |
