| Magnification |
1x - 6x |
| Objective / Field of View |
24mm / 100.4' (33.47m) @ 1x at 100 yds.(100m), 16.6' (5.53m) @ 6x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
30mm |
| Eyepiece Tube Diameter |
Not Specified by Manufacturer |
| Lens Coatings |
Fully Multi Coated Wide Band AR Green |
| Reticle |
Illuminated Red Circle Dot Duplex |
| Reticle Image Plane (Magnifying) |
Second |
| Brightness Adjustments |
0 to 11 Settings |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/2-M.O.A. Per Click with Locking Turrets |
| Maximum Adjustment |
90 MOA W & E |
| Exit Pupil |
16.0mm @ 1x, 4mm @ 6x |
| Eye Relief |
4.3" / 110.0mm @ 1x, 3.5" / 88.0mm @ 6x |
| Parallax Correction Control |
Preset 100 Yards |
| Diopter Adjustment |
+2 to -3 |
| Battery |
CR-2032 |
| Battery Life |
80-150 Hours Depending on Usage |
| Material |
Aluminum Alloy |
| Nitrogen Filled |
Neutral Pressure Nitrogen Purging |
| Waterproof / Fogproof |
Yes |
| Length |
15.4", (390.0mm) |
| Mounting Length |
Not Specified by Manufacturer |
| Weight |
19.4 oz., 550.0g |
| Special Features |
Reticle Image in the Second Focal Plane. Maximum recoil (G's) 1000G Illuminated Red Reticle. Limited Lifetime Warranty |
