| Drive Mode |
Photo Mode: Single-shot / Self-timer |
| Shutter Speeds |
Auto Control Range: 1 / 4 - 1 / 4000; Self-timer: 10sec. (Still Image); Standard: 1 / 60-1 / 500; Auto: 1 / 60 - 1 / 500; Scene Selection: 1 / 60 - 1 / 4000 1 / 4 - 1 / 500 (Candle mode / "MOVIE" position only); Auto (Auto Slow Shutter ON): 1 / 30 - 1 / 500; Auto (Auto Slow Shutter OFF): 1 / 60 - 1 / 500 |
| Focus System |
Contrast AF |
| AF Modes |
Auto / Manual (Touch Panel) |
| Focus Area |
Full range Focus / Spot Focus |
| AF Illuminator |
Yes |
| Camera Type |
Digital STD Video Camera Recorder |
| Quick On |
Yes (Power On by LCD) |
| Manual / Auto Lens Cover |
Auto |
| S/S & Zoom button on LCD |
Yes (Touch Panel) |
| Fader Effect(s) |
White / Black |
| Date / Time Stamp |
Yes (Rec Date / Time, Camera info) |
| Erase/Protect |
Yes / Yes |
| Media/Battery Indicator |
Yes / Yes |
| Power Save Mode |
Auto Shut-off (5 minutes) |
| Still Image Playback Options |
Slide Show; Playback Zoom (1.1 x -5x) (TouchPanel + Zoom Lever) |
| Built-in USB Cable |
Yes (USB Charge Available) |
| Built-in Video Light Coverage |
Approx. 30cm-150cm |
| Menu Customization |
Yes |
| Multiple Language Display |
English; Simplified English; Brazilian Portuguese; Canadian French; Latin American Spanish |
| One Touch Disc Burn |
Yes (Menu) |
| View & Index |
Data Index / Film Roll / Face |
| Media Type |
Optional Memory Stick Duo, Memory Stick PRO Duo, Memory Stick PRO-HG Duo, SD, SDHC |
| Still Image Mode |
JPEG |
| Still Image Max Effective Resolution |
470K pixels |
| Video Format |
MPEG2-PS |
| Video Mode |
HQ: 9Mbps / SP: 6Mbps / LP: 3Mbps |
| Video Resolution |
720 x 480/60i |
| Video Actual (Pixel) |
Approx. 410K pixels (16:9), Approx. 470K pixels (4:3) |
| Video Signal |
NTSC color, EIA standards |
| Photo Capture from Movie |
307K pixels 4:3 (640 x 480); 230K pixels 16:9 (640 x 360) |
| Audio Format |
Dolby Digital 2ch Stereo, Dolby Digital Stereo Creator |
| Microphone/Speaker |
Built-in Zoom Microphone; Monaural Speaker |
| Mic Level Control |
Yes |
| Still Image File Format |
DCF Ver. 2.0 compatible, Exif Ver. 2.21 compatible, MPF Baseline compatible |
| Still Image Size(Photo Mode) |
307K pixels 4:3 (640 x 480); 230K pixels 16:9 (640 x 360) |
| Wind Position |
Yes (Auto) |
| Battery Type |
Lithium-ion type NP-FV30, Manganese Dioxide Lithium type ML621 |
| Battery Capacity |
Typical: 3.6Wh (500mAh), Minimum: 3.6Wh (500mAh) |
| Power Requirements |
7.2V (battery pack); 8.4V (AC Adaptor) |
| LCD Type |
3.0" Touch-screen Clear Photo LCD Plus (230K pixels) |
| Angle Adjustment |
Opening Angle: max. 90 deg., Turning Angle: max. 270 deg. |
| Brightness Control |
Yes (LCD Backlight Level, LCD Bright) |
| Coverage |
1 |
| Live View |
Yes |
| Grid Display |
Guide Frame |
| Touch Panel |
Yes |
| Supplied Software |
Picture Motion Browser Ver. 5.3 |
| Operating System Compatibility |
Microsoft Windows XP SP3, Windows Vista SP2, Windows 7. PMB software is not Mac compatible |
| Metering Modes |
Multi-segment / Spot |
| Exposure Settings |
Auto; Flexible Spot (Touch Panel) |
| Scene Mode(s) |
Auto / Twilight / Candle / Sunrise & Sunset / Fireworks / Landscape / Portrait / Spotlight / Sports / Beach / Snow |
| Noise Reduction |
Yes |
| White Balance Mode |
Auto / Onepush / Outdoor / Indoor |
| Minimum Illumination |
Auto Slow Shutter: 3 lux (1/30 Shutter Speed) |
| Auto Iris Control |
F1.8-F26 |
| Backlight Compensation |
Yes (Auto) |
| Gain Control |
Auto |
| Face Detection |
Yes |
| Image Stabilization |
Electrical SteadyShot image stabilization w / Active mode (Wide to Tele) |
| Intelligent Auto |
Portrait / Tripod / Backlight / Landscape / Spotlight / Twilight / Macro |
| Imaging Sensor |
1/8" (2.25mm ) Advanced HAD (Hole Accumulation Diode) CCD Imager |
| Processor |
Sony Imaging processor |
| Pixel Gross |
Approx. 680K pixels |
| Effective Picture Resolution |
Approx. 470K pixels (4:3) |
| Color Filter System |
YeCyMgG mosaic filters |
| Lens Type |
Carl Zeiss Vario-Tessar |
| Aperture |
F1.8 - F6.0 |
| Optical Zoom |
60x |
| Digital Zoom |
2000x |
| Focal Length (35mm equivalent) |
Photo Mode: 39mm - 2340mm (16:9), 38mm - 2280mm (4:3); Movie Mode: 39mm - 2340mm (16:9), 38mm - 2280mm (4:3) |
| Filter Diameter |
37mm |
| Minimum Focus Distance |
Approx. 1cm (Wide), Approx. 150cm (Tele), Approx. 38cm (Tele Macro) |
| Extended Zoom |
70x |
| Focal Distance |
f = 1.8mm - 108mm |
| Steady Shot Mode |
Active: 46mm - 2760mm (16:3) |
| Memory Card Slot |
Memory Stick PRO Duo and SD/SDHC/SDXC media compatible |
| SD Output |
Composite Video Out (A/V connecting cable (supplied)); S Video Out (A/V connecting cable with S Video) |
| USB Port(s) |
TypeA, mini-AB/USB2.0 Hi-speed (mass-storage) |
| DVDirect |
Yes (DVDirect Express, DVD Writer supported) |
| Remote Jack |
A/V Remote terminal |
| Direct Copy |
Yes |
| A/V Remote Terminal |
Video /S Video /Audio / Remote |
| DC IN |
Yes |
| Dimensions |
2-1/8" x 2-1/4" x 4-7/8" / 52.5 x 57 x 123.5 mm |
| Weight |
Main unit only: 8.1 oz / 230 g |
