| Format(s) Supported |
HDV (MPEG2) / DV (AVI) |
| Video Recording System |
Real-Time HD Codec Engine, HDV/DV Recording |
| Video Signal |
NTSC color, EIA standards |
| Assignable Dial |
N/A |
| Docking Station |
N/A |
| Flash |
N/A |
| Lens Cover Type |
Manual |
| Memory Stick slot |
Memory Stick PRO Duo Media slot |
| S/S & Zoom button on LCD |
Yes (Zoom Seesaw/ Ring/ Handle seesaw) |
| Imaging Device |
3x 1/3" ClearVid CMOS sensor |
| Pixel Gross |
3x 1,120K each (Red, Green, Blue) |
| Processor |
EIP (Enhanced Imaging Processor) |
| Recording and Playback Times |
HDV: up to 60 min. (with DVM60 cassette), DV: SP: up to 60 min., LP: up to 90 min. |
| Recording Media |
MiniDV Cassette (sold separately) |
| Still Actual |
1,080×810 (4:3), 1,440×810 (16:9) |
| Still Picture Resolution |
1.2 megapixel |
| Video Actual |
3x 1037K (16:9) each (Red, Green, Blue) |
| Video Resolution |
Full HD 1440x1080 |
| Battery Type |
InfoLITHIUM® Rechargeable Battery (NP-F570) |
| Power Consumption |
6.5W |
| Power Requirements |
7.2V (battery pack); 8.4V (AC Adaptor) |
| Audio Format |
Stereo MPEG1 Audio Layer |
| Dolby® Digital Output |
HD: HDV (MPEG1 Audio Layer II) / SD: DV ( 12/16bit PCM Digital Stereo) |
| Microphone |
Yes (Built-in) |
| Recording Format |
Stereo |
| Accessory Shoe |
Yes (Cold) |
| Dual Record |
Yes |
| Face Detection |
N/A |
| Hybrid/Hybrid Plus |
N/A |
| Memory Stick PRO Media Compatibility |
Tested to support up to 16GB media capacity; does not support high speed transfer function; does not support Access Control security function. |
| Minimum Illumination |
1.5 Lux |
| Quick On |
N/A |
| SteadyShot® Image Stabilization |
Yes (Optical) |
| Still Image Mode(s) |
JPEG |
| USB Streaming |
N/A |
| White Balance |
Auto / outdoor / indoor / One-push (A/B) |
| Smile Shutter |
N/A |
| Easy Operation |
Assignable Buttons, End Search |
| Fader Effect(s) |
Black, White |
| Movie Mode(s) |
MPEG2 |
| Multiple Language Display |
Yes |
| Picture Effect(s) |
CinemaTone Gamma, CinemaTone Color and Shot Transition |
| Remote Control |
Yes (RMT-831) |
| Scene Mode(s) |
Picture Profile (upto 6 pre-set conditions) |
| White Balance |
Auto / outdoor / indoor / One-push (A/B) |
| x.v.Color |
Yes |
| 35mm Equivalent |
29.5 - (16:9), 36.1 - 722mm (4:3) |
| Aperture |
f1.6-3.4 |
| Digital Zoom |
30x approx. (When Digital Extender "ON") |
| Exposure |
N/A |
| Filter Diameter |
72mm |
| Focal Distance |
4.1 - 82mm |
| Focus |
Full Range Auto, Manual (Ring), One Touch |
| Lens Type |
G Lens |
| Minimum Illumination |
1.5 Lux |
| Optical Zoom |
20x |
| Progressive Shutter Mode |
N/A |
| Shutter Speed |
AUTO 1/50- 1/1750 (50i/25p)- MANUAL 1/3 - 1/10000(25p) |
| LCD Screen |
3.2" wide Xtra Fine LCD display1 (921k pixels) |
| Viewfinder |
0.45" Xtra Fine (16:9) Wide LCD1 (1,227k pixels) |
| Active Interface Shoe |
Yes (Cold) |
| Analog Audio/Video Output(s) |
Multi AV (Video/S Video/Audio) |
| Audio/Video Remote Terminal |
Yes |
| Component Video (Y/Pb/Pr) Output(s) |
Yes (via multi AV) |
| Digital Audio/Video Input(s) |
Yes (via i.LINK®) |
| Digital Audio/Video Output(s) |
Yes (via i.LINK®, HDMI) |
| HDMI Connection Output(s) |
Yes |
| Headphone Jack |
Yes (Stereo Mini) |
| i.LINK® Interface |
Yes |
| LANC Terminal |
Yes (Stereo Mini) |
| Microphone Input |
Yes (Stereo Mini) |
| S-Video Output(s) |
Included in A/V Jack |
| USB Port(s) |
N/A |
| Operating System Compatibility |
N/A |
| Supplied Software |
N/A |
| Dimensions (Approx.) |
6 3/4 x 7 x 13 7/8 inch (169 × 178 × 349mm) including protrusions w/o gripbelt |
| Weight (Approx.) |
4 lb 9 oz (2.1kg) w/ Lens hood with Lens cover |
| Limited Warranty Term |
ADORAMA 90 DAY WARRANTY |
