| Color Filter System |
RGB primary color filters |
| Effective Picture Resolution |
Approx.1310K pixels(16:9) |
| Imaging Sensor |
1/5.8" (3.1mm) Back-illuminated Exmor R CMOS Sensor |
| Pixel Gross |
Approx.1500K pixels |
| Processor |
BIONZ Image processor |
| Still Image Size 4:3 |
Movie mode: 4.0 megapixels 4:3 (2304x1728); Photo mode: 4.0 megapixels 4:3 (2304x1728) |
| Video Mode |
HD FX: Approx. 24Mbps / FH: Approx. 17Mbps / HQ: Approx. 9Mbps / LP: Approx. 5Mbps; STD HQ: 9Mbps |
| Audio Format |
Dolby Digital 2ch Stereo, Dolby Digital Stereo Creator |
| Dual Record |
5.3 megapixels 16:9 (3072 x 1728); 1.3 megapixels 16:9 (1536 x 864) |
| Media Type |
Memory Stick PRO Duo (Mark 2); Memory Stick PRO-HG Duo; SD/ SDHC/ SDXC Memory Card (Class 4 or Higher) |
| Mic Level Control |
Yes (2steps) |
| Microphone/Speaker |
Built-in Zoom Microphone; Monaural Speaker |
| Photo Capture from Movie |
2.1 megapixels 16:9 (1920x1080); 0.3 megapixels 4:3 (640x480); 0.2 megapixels pixels 16:9 (640x360) |
| Still Image File Format |
DCF Ver. 2.0 compatible, Exif Ver. 2.3 compatible, MPF Baseline compatible |
| Still Image Max Effective Resolution |
5.3 megapixels |
| Still Image Mode |
JPEG |
| Still Image Size 16:9 |
Movie mode:5.3 megapixels 16:9 (3072x1728); Photo mode::5.3 megapixels 16:9 (3072x1728) |
| Video Actual (Pixel) |
Approx.1310K pixels(16:9), Approx.980K pixels(4:3) |
| Video Format |
HD: MPEG4-AVC/H.264 AVCHD 2.0 format compatible; STD: MPEG2-PS |
| Video Resolution |
HD: 1920x1080/60i (FX, FH), 1440x1080/60i (HQ, LP); STD: 720x480/60i |
| Video Signal |
NTSC color, EIA standards |
| Wind Position |
Yes(Off/On) |
| Focal Length (35mm equivalent) |
Movie Mode: 36mm - 1080mm (16:9),44mm-1320mm (4:3); Photo Mode: 36mm - 900mm (16:9), 44mm-1100mm (4:3) |
| Aperture |
F1.8-3.2 |
| Digital Zoom |
300x |
| Extended Zoom |
30x |
| Focal Distance |
f = 2.5mm - 62.5mm; f =1/8inch - 2 1/2inch |
| Lens Stabilization |
SteadyShot image stabilization w/ Active mode (Wide to Tele) |
| Lens Type |
Carl Zeiss Vario-Tessar Lens |
| Minimum Focus Distance |
Approx. 1cm (Wide), Approx. 80cm (Tele), Approx. 39cm (Tele Macro) |
| Optical Zoom |
25x |
| Steady Shot Mode |
43.2mm - 1080mm |
| Angle Adjustment |
Opening Angle: max. 90 deg., Turning Angle: max. 270 deg. |
| Brightness Control |
Yes (Menu) |
| Coverage |
1 |
| Grid Display |
Guide Frame |
| LCD Type |
2.7" Clear Photo LCD display (230K) Wide(16:9) |
| Touch Panel |
Yes |
| Shutter Speeds |
Self-timer: Approx. 10sec. (Still Image); Shutter Speed (Standard): 1/60 - 1/10000; Shutter Speed Auto Control Range: 1/8 - 1/10000; Scene Selection: 1/8 - 1/10000; LOW LUX: 1/30 - 1/10000 |
| Drive Mode |
Photo Mode: Single-shot/Self-timer |
| Self-timer |
10sec.(Still Image) |
| Auto Iris Control |
F1.8 - F10 |
| Backlight Compensation |
Yes (Auto) |
| D-Range Optimizer |
Yes |
| Exposure Settings |
Auto; Flexible Spot (Touch Panel) |
| Gain Control |
Auto |
| LOW LUX Mode |
Yes |
| Metering Modes |
Multi-segment / Spot |
| Minimum Illumination |
Standard: 11 lux (1/60 Shutter Speed); Low Lux: 3 lux (1/30 Shutter Speed) |
| Noise Reduction |
Yes |
| Scene Mode(s) |
Auto/Night Scene/Sunrise & Sunset/Fireworks/Landscape/Portrait/Spotlight/Beach/Snow |
| White Balance Mode |
Auto / Onepush / Outdoor / Indoor |
| Tracking Focus |
Yes |
| Face Detection |
Yes |
| Image Stabilization |
SteadyShot image stabilization w/ Active mode (Wide to Tele) |
| Intelligent Auto |
Portrait/Baby/Tripod/Backlight/Landscape/Spotlight/Twilight/Macro/Low light |
| Priority Setting (for Face Detection) |
Auto / Child Priority / Adult Priority |
| Smile Shutter technology |
Dual Capture / Always On / Off |
| x.v.Color |
Yes |
| AF Modes |
Auto/Manual(Touch Panel) |
| Focus Area |
Full range Focus / Spot Focus |
| Focus Type |
Tracking Focus |
| Focus System |
Contrast AF |
| Built-in USB Cable |
Yes (USB Charge Available) |
| Date / Time Stamp |
Yes (Rec Date and Time, Camera info, Coordinates) |
| Erase/Protect |
Yes / Yes |
| Fader Effect(s) |
White / Black |
| Manual / Auto Lens Cover |
Manual |
| Media/Battery Indicator |
Yes (recordable time, free and used media space) / Yes (recordable time, remaining capacity) |
| Multiple Language Display |
English; Simplified English; Brazilian Portuguese; Canadian French; Latin American Spanish |
| One Touch Disc Burn |
Yes (Menu) |
| Quick On |
Yes (Power On by LCD) |
| S/S & Zoom button on LCD |
Yes (Touch Panel) |
| Still Image Playback Options |
Slide Show |
| Video Playback Options |
Highlight Playback (HD Movie Only); Highlight Playback Save and Share (Translate into STD quality); Highlight Scenario (Save/Playback/Erase); Highlight BGM (Preinstalled 4 music files, Music transfer) |
| View & Index |
Event |
| Resolution Output |
640 x 360 |
| Throw Distance |
16ft (5m) (for 100"diagonal) |
| SD Output |
Composite Video Out(A/V connecting cable(supplied) |
| Remote Jack |
Integrated into A/V Remote terminal |
| A/V Remote Terminal |
Video / Audio / Remote |
| BRAVIA Sync |
Yes |
| DC IN |
Yes |
| HD Output |
HDMI Out(mini)(supplied) |
| HDMI Terminal |
Yes (mini) |
| Memory Card Slot |
Memory Stick PRO Duo and SD/ SDHC/ SDXC media compatible |
| PhotoTV HD |
Yes |
| USB Port(s) |
TypeA, mini-AB/USB2.0 Hi-speed (mass-storage/MTP) |
| Power Consumption |
HD: 2.1W; STD: 1.9W (in Operation) HD:3.0W; STD:2.8W (in View Finder Operation) |
| Battery Type |
Info LITHIUM with AccuPower Meter System (NP-FV30) |
| Power Requirements |
6.8V/7.2 (battery pack); 8.4V (AC Adaptor) |
| Dimensions |
2.37 inch x 2.25 inch x 4.25 inch (58mm x 56mm x 114mm) |
| Weight |
7.4oz (210g) |
