| Focal Length (35mm equivalent) |
Movie Mode 26.8mm - 321.6mm (169), 32.8mm-393.6mm (43); Photo Mode 26.8mm - 321.6mm (169), 32.8mm-393.6mm (43) |
| Aperture |
F1.8-3.4 |
| Digital Zoom |
160x |
| Extended Zoom |
20x |
| Filter Diameter |
30mm |
| Focal Distance |
f = 2.9mm - 34.8mm; f =1/8inch - 1 3/8inch |
| Lens Stabilization |
Optical SteadyShot image stabilization w/ Active mode (Wide to Tele) |
| Lens Type |
G Lens |
| Minimum Focus Distance |
1cm (Wide), 50cm (Tele), 25cm (Tele Macro) |
| Optical Zoom |
12x |
| Steady Shot Mode |
Active 29.1-582.7mm |
| Auto Iris Control |
F1.8 - F10 |
| Backlight Compensation |
Yes (Auto) |
| D-Range Optimizer |
Yes |
| Exposure Settings |
Auto; Flexible Spot (Touch Panel) |
| Gain Control |
Auto |
| LOW LUX Mode |
Yes |
| Metering Modes |
Multi-segment / Spot |
| Minimum Illumination |
Standard 6 lux (1/50 Shutter Speed); Low Lux 3 lux (1/25 Shutter Speed) |
| Noise Reduction |
Yes |
| Scene Mode(s) |
Auto / Twilight / Twilight Portrait (Photo Mode only) / Sunrise & Sunset / Fireworks / Landscape / Portrait / Spotlight / Beach / Snow |
| White Balance Mode |
Auto / Onepush / Outdoor / Indoor |
| Endurance (Battery Life) |
85mim(Supplied Battery) |
| Resolution Output |
640x360 |
| Throw Distance |
16ft (5m) (for 100"diagonal) |
| SD Output |
Composite Video Out (A/V connecting cable (supplied)); Component Video Out (Component A/V cable (supplied)); S Video Out (A/V connecting cable with S Video (sold separately)) |
| Remote Jack |
Integrated into A/V Remote terminal |
| Remote Commander |
Yes |
| A/V Remote Terminal |
Video / Audio / Remote |
| Accessory Shoe |
Yes (Active Interface Shoe) |
| BRAVIA Sync |
Yes |
| DC IN |
Yes |
| Direct Copy |
Yes |
| HD Output |
HDMI Out (mini) (supplied) |
| HDMI Terminal |
Yes (mini) |
| Headphone Jack |
Stereo Minijack |
| Memory Card Slot |
Memory Stick PRO Duo and SD/ SDHC/ SDXC media compatible |
| Microphone Input |
Stereo Minijack |
| PhotoTV HD |
Yes |
| USB Port(s) |
TypeA, mini-AB/USB2.0 Hi-speed (mass-storage/MTP) |
| Color Filter System |
ClearVid array |
| Effective Picture Resolution |
5020K pixels (169) |
| Imaging Sensor |
1/3.91" (4.6mm) Back-illuminated Exmor R CMOS Sensor |
| Pixel Gross |
5430K pixels |
| Processor |
BIONZ Image processor |
| Angle Adjustment |
Opening Angle max. 90 deg., Turning Angle max. 270 deg. |
| Brightness Control |
Yes (Menu) |
| Coverage |
1 |
| Grid Display |
Guide Frame |
| LCD Type |
3.0" Xtra Fine LCD display (921K) w/ TruBlack technology |
| Touch Panel |
Yes |
| Shutter Speeds |
Self-timer 10sec. (Still Image/ Golf Shot); Shutter Speed (Standard) 1/50 - 1/10000; Shutter Speed Auto Control Range 1/8 - 1/10000; Shutter Speed (Smooth Slow Rec) 1/250 - 1/10000 (Standard); Scene Selection 1/8 - 1/10000; LOW LUX 1/25 - 1/10000 |
| Drive Mode |
Photo Mode Single-shot / Self-timer |
| Self-timer |
10sec.(Still Image/Golf Shot) |
| Built-in USB Cable |
Yes (USB Charge Available) |
| Date / Time Stamp |
Yes (Rec Date and Time, Camera info, Coordinates) |
| Erase/Protect |
Yes / Yes |
| Fader Effect(s) |
White / Black |
| Manual / Auto Lens Cover |
Auto |
| Media/Battery Indicator |
Yes (recordable time, free and used media space) / Yes (recordable time, remaining capacity) |
| Multiple Language Display |
English; Simplified English; Brazilian Portuguese; Canadian French; Latin American Spanish |
| One Touch Disc Burn |
Yes (Menu) |
| Power Save Mode |
Auto Shut-off(1minute) Eco mode "MAX"; Auto Shut-off(2minutes) Eco mode "Standard" |
| Quick On |
Yes (Power On by LCD) |
| Red-Eye Reduction |
Yes (On / Off) |
| S/S & Zoom button on LCD |
Yes (Touch Panel) |
| Still Image Playback Options |
Slide Show |
| Video Playback Options |
Highlight Playback (HD Movie Only); Highlight Playback Save and Share (Translate into STD quality); Highlight Scenario (Save/Playback/Erase); Highlight BGM (Preinstalled 4 music files, Music transfer) |
| View & Index |
Event / MAP |
| Still Image Size 4:3 |
Movie mode 15.3 megapixels 43 (4512x3384); Photo mode 15.3 megapixels 43 (4512x3384) |
| Video Mode |
HD PS 28Mbps / FX 24Mbps / FH 17Mbps / HQ 9Mbps / LP 5Mbps; STD HQ 9Mbps |
| Audio Format |
Dolby Digital 5.1ch, Dolby Digital 5.1Creator; Dolby Digital 2ch Stereo, Dolby Digital Stereo Creator |
| Dual Record |
20.4 megapixels 169 (6016x3384); 10.0 megapixels 169 (4224x2376); 2.1 megapixels 169 (1920x1080) |
| Internal Media |
Flash Memory 32GB |
| Media Type |
Internal Flash Memory; Memory Stick PRO Duo (Mark 2); Memory Stick PRO-HG Duo; SD/ SDHC/ SDXC Memory Card (Class 4 or Higher) |
| Mic Level Control |
Yes (2steps) |
| Microphone/Speaker |
Built-in Zoom Microphone; Clear Phase Stereo Speaker |
| Photo Capture from Movie |
2.1 megapixels 169 (1920x1080); 0.3 megapixels 43 (640x480); 0.2 megapixels pixels 169 (640x360) |
| Recording and Playback Times |
HD PS 2h20m (2h20m); HD FX 2h45m (2h45m); HD FH 3h50m (2h45m); HD HQ 6h50m (6h10m); HD LP 11h55m (7h5m); STD HQ 7h5m (6h35m) (in Internal Media)(2ch) |
| Recording and Playback Times |
HD PS 2h20m; HD FX 2h45m; HD FH 3h45m; HD HQ 6h40m; HD LP 11h35m; STD HQ 6h55m (in Internal Media)(5.1ch) |
| Still Image File Format |
DCF Ver. 2.0 compatible, Exif Ver. 2.3 compatible, MPF Baseline compatible |
| Still Image Max Effective Resolution |
20.4 megapixels |
| Still Image Mode |
JPEG |
| Still Image Size 16:9 |
Movie mode 20.4 megapixels 169 (6016x3384); Photo mode 20.4 megapixels 169 (6016x3384) |
| Video Actual (Pixel) |
5,020K pixels(169), 3,760K pixels(43) |
| Video Format |
HD MPEG4-AVC/H.264 AVCHD 2.0 format compatible (1080/60poriginal format); STD MPEG2-PS |
| Video Resolution |
HD 1920x1080/60p (PS), 24p, 60i (FX, FH), 1440x1080/60i (HQ, LP); STD 720x480/60i |
| Video Signal |
PAL |
| Wind Noise Reduction |
Yes (Off /On) |
| Power Consumption (in Operation) |
HD 3.1W; STD 2.9W |
| Battery Type |
InfoLITHIUM with AccuPower Meter System (NP-FV50) |
| Power Consumption |
HD 3.0W; STD 2.8W (in View Finder Operation) |
| Power Requirements |
6.8V/7.2 (battery pack); 8.4V (AC Adaptor) |
| Flash Compensation |
Yes (3 steps) |
| Flash Coverage |
0.3m - 2.0m |
| Dimensions |
3-5/8 x 30-1/4 x 6in (90 x 82 x 151.5mm) (including Lens Hood) |
| Weight |
12.16oz (345g) |
