| Color Filter System |
ClearVid array |
| Effective Picture Resolution |
2230K pixels (16:9) |
| Imaging Sensor |
1/3.91" (4.6mm) Back-illuminated Exmor R CMOS Sensor |
| Pixel Gross |
5430K pixels |
| Processor |
BIONZ Image processor |
| Still Image Size 4:3 |
Movie mode: 6.7 megapixels 4:3 (2992x2240); Photo mode: 6.7 megapixels 4:3 (2992x2240) |
| Video Mode |
HD PS: 28Mbps / FX: 24Mbps / FH: 17Mbps / HQ: 9Mbps / LP: 5Mbps; STD HQ: 9Mbps |
| Audio Format |
Dolby Digital 5.1ch, Dolby Digital 5.1Creator; Dolby Digital 2ch Stereo, Dolby Digital Stereo Creator |
| Dual Record |
8.9 megapixels 16:9(3984x2240); 4.5 megapixels 16:9(2816x1584); 2.1 megapixels 16:9 (1920x1080) |
| Internal Media |
HDD 160GB |
| Media Type |
Internal hard drive; Memory Stick PRO Duo (Mark 2); Memory Stick PRO-HG Duo; SD/ SDHC/ SDXC Memory Card (Class 4 or Higher) |
| Mic Level Control |
Yes (2steps) |
| Microphone/Speaker |
Built-in Zoom Microphone; Clear Phase Stereo Speaker |
| Photo Capture from Movie |
2.1 megapixels 16:9 (1920x1080); 0.3 megapixels 4:3 (640x480); 0.2 megapixels pixels 16:9 (640x360) |
| Recording and Playback Times (2ch) |
HD PS: 13h0m ( 13h0m); HD FX: 15h20m ( 15h20m); HD FH: 20h50m ( 20h50m); HD HQ: 36h40m ( 27h50m); HD LP: 63h10m ( 52h0m); STD HQ: 37h50m ( 34h50m) |
| Still Image File Format |
DCF Ver. 2.0 compatible, Exif Ver. 2.3 compatible, MPF Baseline compatible |
| Still Image Max Effective Resolution |
8.9 megapixels |
| Still Image Mode |
JPEG |
| Still Image Size 16:9 |
Movie mode: 8.9 megapixels 16:9 (3984x2240); Photo mode: 8.9 megapixels 16:9 (3984x2240) |
| Video Actual (Pixel) |
2,230K pixels(16:9), 1,670K pixels(4:3) |
| Video Format |
HD: MPEG4-AVC/H.264 AVCHD 2.0 format compatible (1080/50p:original format); STD: MPEG2-PS |
| Video Resolution |
HD: 1920x1080/50p (PS), 24p, 50i (FX, FH), 1440x1080/50i (HQ, LP); STD: 720x480/50i |
| Video Signal |
PAL |
| Wind Noise Reduction |
Yes (Off /On) |
| Angle Adjustment |
max. 270 deg. |
| Brightness Control |
Yes (Menu) |
| Coverage |
1 |
| Grid Display |
Guide Frame |
| LCD Type |
3.0" Clear Photo LCD display (230K) Wide(16:9) |
| Touch Panel |
Yes |
| Focal Length (35mm equivalent) |
Movie Mode: 29.8mm - 894mm (16:9), 36.5mm-1095mm (4:3); Photo Mode: 29.8mm - 894mm (16:9), 36.5mm-1095mm (4:3) |
| Aperture |
F1.8-3.4 |
| Digital Zoom |
350x |
| Extended Zoom |
55x |
| Focal Distance |
f = 2.1mm - 63.0mm; f =3/32inch - 2.25 inch |
| Lens Stabilization |
Optical SteadyShot image stabilization w/ Active mode (Wide to Tele) |
| Lens Type |
G Lens |
| Minimum Focus Distance |
1cm (Wide), 80cm (Tele), 44cm (Tele Macro) |
| Optical Zoom |
30x |
| Shutter Speeds |
Self-timer: 10sec. (Still Image/ Golf Shot); Shutter Speed (Standard): 1/25 - 1/10000; Shutter Speed Auto Control Range:.13 - 1/10000; Shutter Speed (Smooth Slow Rec):.25 50 - 1/10000 (Standard); Scene Selection:.13 - 1/10000; LOW LUX: 1/25 - 1/10000 |
| Drive Mode |
Single-shot / Self-timer |
| Self-timer |
10sec.(Still Image/Golf Shot) |
| Auto Iris Control |
F1.8 - F10 |
| Backlight Compensation |
Yes (Auto) |
| D-Range Optimizer |
Yes |
| Exposure Settings |
Auto; Flexible Spot (Touch Panel) |
| Gain Control |
Auto |
| LOW LUX Mode |
Yes |
| Metering Modes |
Multi-segment / Spot |
| Minimum Illumination |
Standard: 6 lux (1/50 Shutter Speed); Low Lux: 3 lux (1/25 Shutter Speed) |
| Noise Reduction |
Yes |
| Scene Mode(s) |
Auto/Night Scene/Sunrise & Sunset/Fireworks/Landscape/Portrait/Spotlight/Beach/Snow |
| White Balance Mode |
Auto / Onepush / Outdoor / Indoor |
| SD Output |
Composite Video Out (A/V connecting cable (supplied) |
| Remote Jack |
Integrated into A/V Remote terminal |
| A/V Remote Terminal |
Video / Audio / Remote |
| BRAVIA Sync |
Yes |
| DC IN |
Yes |
| HD Output |
HDMI Out (mini) (supplied) |
| HDMI Terminal |
Yes (mini) |
| Headphone Jack |
Stereo Minijack |
| Memory Card Slot |
Memory Stick PRO Duo and SD/ SDHC/ SDXC media compatible |
| Microphone Input |
Stereo Minijack |
| PhotoTV HD |
Yes |
| USB Port(s) |
TypeA, mini-AB/USB2.0 Hi-speed (mass-storage/MTP) |
| Tracking Focus |
Yes |
| Embedded GPS |
Yes (Current Position Display (Your Location)) |
| Face Detection |
Yes |
| Golf Shot |
Yes |
| Image Stabilization |
Optical SteadyShot image stabilization w/ Active mode (Wide to Tele) |
| Intelligent Auto |
Portrait/Baby/Walk/Tripod/Backlight/Landscape/Spotlight/Twilight/Macro/Low light/Auto wind noise reduction |
| Priority Setting (for Face Detection) |
Auto / Child Priority / Adult Priority |
| Smile Shutter technology |
Dual Capture / Always On / Off |
| Smooth Slow Rec |
Yes |
| x.v.Color |
Yes |
| AF Illuminator |
Yes |
| AF Modes |
Auto / Manual (Touch Pane) |
| Focus Area |
Full range Focus / Spot Focus |
| Focus Type |
Tracking Focus |
| Focus System |
Contrast AF |
| Built-in USB Cable |
Yes (USB Charge Available) |
| Date / Time Stamp |
Yes (Rec Date and Time, Camera info, Coordinates) |
| Erase/Protect |
Yes / Yes |
| Fader Effect(s) |
White / Black |
| Manual / Auto Lens Cover |
Auto |
| Media/Battery Indicator |
Yes (recordable time, free and used media space) / Yes (recordable time, remaining capacity) |
| One Touch Disc Burn |
Yes (Menu) |
| Quick On |
Yes (Power On by LCD) |
| Red-Eye Reduction |
Yes (On / Off) |
| S/S & Zoom button on LCD |
Yes (Touch Panel) |
| Still Image Playback Options |
Slide Show |
| Video Playback Options |
Highlight Playback (HD Movie Only); Highlight Playback Save and Share (Translate into STD quality); Highlight Scenario (Save/Playback/Erase); Highlight BGM (Preinstalled 4 music files, Music transfer) |
| View & Index |
Event / MAP |
| Power Consumption |
HD: 3.5W; STD: 3.2W (in Operation) HD: 3.0W; STD: 2.8W (in View Finder Operation) HD:3.0W; STD:2.8W (in View Finder Operation) |
| Battery Type |
Info LITHIUM with AccuPower Meter System (NP-FV50) |
| Power Requirements |
6.8V/7.2 (battery pack); 8.4V (AC Adaptor) |
| Dimensions |
2.34 inch x 2.59 inch x 5.03 inch (59.5mm x 66mm x 128mm) |
| Weight |
12.52oz (205g) |
