| Signal System |
HDV: 1080/60i DV: 480/60i (NTSC) |
| Image Device |
1/2.9" CMOS ClearVid Sensor |
| Lens |
Carl Zeiss Vario-Sonnar T* Zoom Lens, 10x (Optical) |
| Horizontal Resolution |
1080 Lines |
| Minimum Illumination |
4 Lux f/1.6 at 18 dB |
| LCD Monitor |
Clear Photo LCD Plus, 2.7", 16:9 Aspect Ratio |
| Viewfinder |
132,000 Pixels, 16:9 Aspect Ratio |
| Scan Matching |
Yes |
| Memory Card Slot |
No |
| Gain Selection |
0, 3, 6, 9, 12, 15, 18 dB |
| Tape Format |
DVCAM Small Cassette HDV Record and Play DV Record and Play |
| Tape Speed |
HDV: 18.8 mm/s DV SP Mode: 18.8 mm/s |
| Maximum Recording Time |
HDV: 63 min (with PHDVM-63DM Cassette) DVCAM: 41 min (with PHDVM-63DM Cassette) DV: 63 min (with PHDVM-63DM Cassette) |
| Audio Signal Format |
HDV MPEG1 Audio Layer II DVCAM/DV 16-bit/48kHz 2 Channel Mode 12-bit/32kHz 4 Channel Mode |
| Audio Frequency Response |
20Hz to 20kHz |
| Input and Output Connectors |
Component Video: RCAx3 (x1 Output) Composite Video: RCAx1 (x1 Output) S-Video: 4-Pin mini-DIN (x1 Output) HDV/DV Input/Output: i.LINK interface (IEEE 1394, 4-Pin Connector) Audio L/R Output: RCAx2 Audio Input: Stereo Mini-Jack Headphone: Stereo Mini-Jack LANC: Stereo Mini-Jack USB: Type-B Connector |
| Warranty |
Sony 1 year parts & 90 days labor warranty |
