| Built-In Optical Filters |
ND filters:1: CLEAR, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND |
| Dynamic Range |
600% |
| Effective Picture Elements |
1920 x 1080 |
| Gain Selection |
-3,0,+3,+6,+9,+12db |
| Horizontal Resolution |
1,000 TV lines or more (in 1920 x 1080i mode)
920 TV lines (in SD mode) |
| Lens Mount |
Standard 2/3" B4 Bayonett mount |
| Optical System |
F1.4 Prism system |
| Pickup Device |
3-chip 2/3-inch type Exmor Full-HD CMOS |
| S/N Ratio |
HD 59db, SD 65db (Y=Typical) |
| Sensitivity |
F12 (typical) (1920 x 1080/59.94i mode), F13 (typical) (1920 x 1080/50i mode) (at 2000 lx, 3200 K, 89.9% reflectance) |
| Shutter Speed |
1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000 |
| Application |
Studio/Field operation |
| Format |
1920 x 1080/59.94i, 50i 1280 x 720/59.94P, 50P |
| Imager |
2/3-inch type Exmor Full-HD CMOS |
| Input/Output Connectors: CCU |
26 MULTI PIN CONNECTER(CCZA/CCZAD cable connecter) |
| Input/Output Connectors: Intercom |
XLR 5-pin, female (x1) |
| Input/Output Connectors: Lens |
12-Pin(x1) |
| Input/Output Connectors: Prompter |
BNC (x1), 1 Vp-p, 75 ohm |
| Input/Output Connectors: Remote |
8-pin (x1) |
| Input/Output Connectors: Viewfinder |
Digital interface (x1) and DXF type analog interface (x1) |
| Inputs and Outputs: Audio In |
XLR 3-pin (x2, at front panel and rear panel) |
| Inputs and Outputs: DC In |
XLR 4-pin (x1) |
| Inputs and Outputs: DC Out |
4-pin (x1) |
| Inputs and Outputs: Earphone |
Mini-jack 3-pin (x1) |
| Inputs and Outputs: Genlock In |
BNC (x1), 1 Vp-p, 75 ohm |
| Inputs and Outputs: HD-SDI Out |
BNC (x1) (Dual Link) |
| Inputs and Outputs: Lens |
12-Pin(x1) |
| Inputs and Outputs: MIC In |
XLR 3-pin (x2, at front panel and rear panel) |
| Inputs and Outputs: Memory Stick |
Memory Stick DUO |
| Inputs and Outputs: Remote |
8-pin (x1) |
| Inputs and Outputs: SDI In |
BNC (x1) |
| Inputs and Outputs: Test Out |
BNC (x1) |
| Inputs and Outputs: Video Out |
Test out/SDI OUT |
| Operating Temperature |
-10 deg.C to +45 deg.C (14 deg.F to 113 deg.F) |
| Power Consumption |
Approx. 1.92 A/12v Main unit (camera) + LCD viewfinder + auto focus lens + microphone |
| Power Requirements |
12 V DC (10.5 V to 17.0 V) |
| Storage Temperature |
-20deg.C to +60deg.C (-4deg.F to 140deg.F) |
| Dimensions (W x H x D) |
144 x 314 x 223 mm / 5.75 x 12.37 x 8.87 inches |
| Weight |
Main body only: 3.4 kg (7 lb 7.9 oz) |
