| Built-in Optical Filters |
Clear
1/4
1/16
1/64 |
| Effective Picture Elements |
Approx. 1,037,000 pixels with ClearVid array |
| Gain Selection |
-6
-3
0
3
6
9
12
15
18
21 dB
AGC |
| Minimum Illumination |
1.5 lx (auto gain, auto iris, 1/30 shutter) |
| Shutter Speed (Time) |
Auto, Manual 60i/30p: 1/4-1/10,000, 24p: 1/3-1/10,000 sec. |
| Slow & Quick Motion Function |
120 fps (fixed) as improved Smooth Slow Rec. |
| Slow Shutter |
1/4 sec.
1/8 sec.
1/15 sec.
1/30 sec. |
| Audio Recording |
HD: Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit 48kHz
SD: Dolby Digital 2ch, 16bit, 48kHz |
| Mass |
(w/Lens hood with Lens cover) 2.2 kg (4 lb 15 oz)
(w/NP-F570 Battery, Lens hood with Lens cover, large eyecup, ECM-XM1, Memory card) 2.5 kg (5 lb 7 oz)
(w/NP-F770 Battery, Lens hood with Lens cover, large eyecup, ECM-XM1, Memory card) 2.6 kg (5 lb 11 oz)
(w/NP-F970 Battery, Lens hood with Lens cover, large eyecup, ECM-XM1, Memory card) 2.7 kg (5 lb 14 oz) |
| Operating Temperature |
0 to +40 deg C (+32 to +104 deg F) |
| Power Consumption |
ECM-XM1 and LCD with normal brightness 7.7W (When Flash Memory Unit HXR-FMU128 is used, the average power consumption increases about 1.1W) |
| Power Requirements |
AC adaptor / Battery 8.4V / 7.2V |
| Recording Media |
Memory Stick PRO Duo
Memory Stick PRO Duo (High Speed)
Memory Stick PRO Duo (Mark2)
Memory Stick PRO-HG Duo
Memory Stick PRO-HG Duo HX |
| Recording/Playback Time |
170 min (2h 50m) with 32GB Memory Stick PRO-HX Duo FX (24Mbps) Linear PCM 2ch recording |
| Storage Temperature |
-20 to +60 deg C (-4 to +140 deg F) |
| Video Recording Format |
HD: MPEG-4 AVC/H.264 (AVCHD)
SD: MPEG-2 PS |
| Focal Length |
f = 4.1 to 82.0 mm (equivalent to f = 29.5 to 590 mm at 16:9 mode, f = 36.1 to 722 mm at 4.3 mode on 35 mm lens) |
| Zoom Ratio Selectable |
Sony G Lens, 20x (optical), 1.5x Digital Extender |
| Audio In |
XLR 3-pin (female) (x2)
line/mic/mic +48 V selectable |
| Audio Out |
RCA type (CH-1, CH-2) |
| Component Out |
RCA type (x3) via A/V multi connector |
| Composite Video Out |
RCA type (x1) |
| DC In |
Power cord |
| Remote |
Yes |
| SDI Out |
BNC (x1)
HD-SDI/SD-SDI selectable |
| USB |
Mini-B (x1) |
| Built-in LCD Monitor |
3.2 inch-type, XtraFine LCD, approximately 921,600 dots, hybrid type, 16:9 aspect ratio |
| Viewfinder |
0.45 inch-type approximately 1,226,880 dots (852 x 3(RGB) x 480), 16:9 aspect ratio |
