| Picture Type |
a-Si TFT Active Matrix LCD |
| Resolution |
1920 x 1080 pixels (Full HD) |
| Effective picture size (H x W) |
509.1 x 286.4 mm (20-1/8 x 11-3/8 inches) 584.2 mm (23 inches) |
| Aspect Ratio |
16:9 |
| Colors |
Approx. 16.7 million colors |
| Viewing angle |
89deg./89deg./89deg./89deg. (typical) (up/down/left/right contrast>10:1) |
| Input Composite |
BNC (x1), 1.0 Vp-p ±3dB sync negative |
| Input SDI |
BNC (x2) |
| Parallel remote |
Modular connector 8-pin (x1) (pin-assignable) |
| Serial remote |
RJ-45 modular connector (Ethernet) (x1) (10BASE-T/100BASE-TX) |
| DC in |
DC 24 V (output impedance 0.05 ohms or less) |
| Output Composite |
BNC (x1), Loop-through, with 75 ohms automatic termination |
| SDI |
BNC (x1), Output signal amplitude: 800 mVp-p ±10% Output impedance: 75 ohms unbalanced |
| Audio monitor out |
Stereo mini jack (x1) |
| Speaker (built-in) |
1.0 W (mono) |
| Headphones output |
Stereo mini jack (x1) |
| Power requirements |
AC 100 V to 240 V, 50/60 Hz, 0.8 A to 0.4 A, DC 24 V 2.4 A |
| Power consumption |
Maximum approx. 70 W |
| Operating temperature |
0deg.C to 35deg.C (32deg.F to 95deg.F), Recommended: 20deg.C to 30deg.C (68deg.F to 86deg.F) |
| Operating humidity |
30% to 85% (no condensation) |
| Storage and transport temperature |
-20deg.C to +60deg.C (-4deg.F to +140deg.F) |
| Storage and transport humidity |
0% to 90% |
| Operating, storage/transport pressure |
700 hPa to 1060 hPa |
| Dimensions (W x H x D) |
21.6 x 13.9 x 3.9" (55 x 35.3 x 10 cm) |
| Weight |
20.3 lbs (9.2kg) |
