| CD (CD-DA) |
CD and 8cm CD |
| CD-R/RW |
Yes |
| MPEG Audio |
Yes |
| Subwoofer System |
2-way |
| Timer |
Play/Sleep (Tuner); Play/Sleep (CD Timer) |
| Auto Standby Mode |
Yes |
| Bass Boost function |
DSGX |
| Timer Play |
iPod/iPhone, CD, FM, AM |
| Timer Sleep |
iPod/iPhone, CD, FM, AM |
| Analog Audio Input(s) |
Audio Line: 3.5mm |
| Headphone Jack |
Yes (3.5mm) |
| Front (RMS 10%THD) |
50W x 2 |
| Audio |
Yes |
| CD |
Yes |
| DMPORT |
Yes |
| Port |
Yes |
| Tuner |
Yes |
| iPod |
Yes |
| Power Consumption (in Standby) |
85W (Below 0.5W) |
| Power Requirements |
120V AC, 60Hz |
| Normal |
1 Disc; 1 Folder |
| Program |
Yes |
| Repeat |
Yes |
| Shuffle |
1 Disc; 1 Folder |
| Playable Discs for Audio |
8cm Disc (CD): Yes
CD: Yes
CD-R: Yes
CD-RW: Yes |
| Text Information |
ID3Tag Ver. 1.1: Yes
ID3Tag Ver. 2.0: Yes
MP3 File name: Yes |
| Audio: Antenna System |
Simple Type |
| Audio: Band |
FM/AM |
| Audio: CD Play Mode(s) |
Normal, Shuffle, Program, Repeat |
| Audio: Digital-to-Analog Converter |
44.1kHz/24bit |
| Audio: Equalizer |
Preset EQ: 7 |
| Audio: Format(s) Supported |
CD,CD-R,CD-RW,MP3,8cm Disc (CD) |
| Audio: Frequency Range |
FM 87.5-108.0MHz, AM 531-1710KHz |
| Audio: Impedance |
12 ohms |
| Audio: Speaker Type |
2way |
| Audio: Station Preset(s) |
FM 20/AM 10 |
| Audio Power Output |
Channel-wise Amp Measurement: 50W x 2 |
| Power Save Mode |
Yes |
| Timer Events |
Play/Sleep |
| Battery Type |
Remote Battery Size/Type: AA/Manganese |
| Output Power |
100W Total |
| Tweeter |
Unit: Horn, 4cm |
| Woofer Size(s) |
13cm / 5.11" |
| Tuner Band |
FM/AM |
| External Antenna |
Simple Type |
| Preset Channel |
20 (FM); 10 (AM) |
| Front Speaker: Length of Supplied Cable |
1.5m / 4.92 ft |
| Front Speaker: Tweeter Unit Size |
Horn, 4cm / 1.57" |
| Front Speaker: Woofer Unit Size |
16cm / 6.29" |
| Dimensions |
Main Unit: 8 in x12 in x 13.25 in (203.2 x 304.8 x 336.55mm)
Front Speaker: 7.62 in x12 in x 7.75 in (193.548 x 193.548 x 196.85mm) |
| Weight |
Main Unit: 8 lb 3 oz (3.2Kg)
Front Speaker: 4 lb 11 oz (2.1Kg) |
