| Imaging Device |
Exmor Super35 CMOS Sensor |
| LCD Screen |
3.5 inch-type, XtraFine LCD, approx. 921,600 dots(1920 x 480), 16:9 aspect |
| Microphone |
ECM-XM1 Shotgun type monaural mic. |
| Effective Picture Elements |
3.43 M pixels (2464 x 1394) |
| Gain Selection |
0dB 3dB 6dB 9dB 12dB 15dB 18dB 21dB 24dB 27dB 30dB |
| Minimum Illumination |
0.28 lx (1/30 shutter, IRIS F1.4, Auto GAIN) |
| Optical System |
Single Super35mm size sensor |
| Pickup Device |
Exmor Super35 CMOS Sensor |
| Shutter Speed (Time) |
Auto: 1/60-1/2000, 30p: 1/30-1/2000, 24p: 1/48-1/2400 Manual:60i/30p/60p: 1/3 - 1/10000, 24p: 1/3 - 1/10000 |
| Slow & Quick Motion Function |
REC. Frame rates: 1080/60p, 1080/30p, 1080/24p Camera capture: 60fps, 30fps, 15fps, 8fps, 4fps, 2fps, 1fps |
| Aperture |
F3.5-6.3 |
| Filter Diameter |
67mm (SEL18200 kit lens) |
| Focal Length |
18 to 200mm |
| Focus |
Manual & Auto |
| Image Stabilizer |
Optical SteadyShot Optical SteadyShot with Active Mode |
| Iris |
six blade |
| Lens Type |
SEL18200 E-Mount zoom lens |
| Maximum Relative Aperture |
F 3.5 to 5.6 |
| Optical Zoom |
11.1x |
| Audio In |
XLR 3-pin (female) (x 2), LINE/MIC/MIC with selectable attenuation and +48V phantom power |
| Audio Out |
2 RCA L&R |
| Component Out |
HDMI 1.4 RCA Type (x 3) via Mini-D jack |
| Composite Video Out |
RCA Type (x 1) |
| Earphone |
3.5mm Stereo |
| Lens Connector |
E-Mount Hot Shoe |
| MIC In |
Two 3-Pin XLR with selectable attenuation and phantom power |
| Monitor Speaker |
YES |
| Remote |
LANC type 2.5mm |
| TC Out |
HDMI 1.4 (embedded SMPTE TC Out) |
| Test Out |
Via HDMI 1.4 |
| USB |
mini-AB/Hi-Speed (x 1) |
| Lens Mount |
Sony E-Mount |
| Built-in LCD Monitor |
3.5 inch-type, XtraFine LCD, approx. 921,600 dots(1920 x 480), 16:9 aspect |
| Viewfinder |
Supplied VF tube for LCD |
| Audio Recording Modes |
16-bit 48KHz LPCM or Dolby Digital Stereo 48KHz |
| AVCHD Recording Modes |
HD-FH: YES HD-FX: YES HD-HQ: YES HD-LP: YES PS: YES, 1920x1080 60P (59.97P) |
| Continuous Operating Time |
Approx. 510 min (NP-F970: fully charged battery.) |
| Operating Temperature |
+32 to +104 degrees F (0 to +40 degrees (C) |
| Power Consumption |
5.6W (w/ supplied lens) 6.7W with HXR-FMU128 |
| Power Requirements |
AC adaptor / Battery) 8.4V / 7.2V |
| Recording Frame Rate NTSC Mode |
PS (28Mbps) 1920x1080 60p, HD FX (24Mbps) 1920x1080 30p HD FX (24Mbps) 1920x1080 24p, HD FX (24Mbps) 1920x1080 60i, HD FH (17Mbps) 1920x1080 60i, HD HQ (9Mbps) 1440x1080 60i, HD LP (5Mbps) 1440x1080 60i, HD FH (17Mbps),1920x1080 24p, HD FH (17Mbps) 1920x1080 30p, HD FX (24Mbps), 1280x720 60p, HD FH (17Mbps) 1280x720 60p HQ (9Mbps) 720x480/60i (30p Scan) , HQ (9Mbps), 720x480/60i (24p Scan) |
| Recording Media |
HXR-FMU128optional 128 GB Memory Module SD/SDHC/SDXC Memory Card Memory Stick PRO Duo Mark2 Memory Stick PRO-HG Duo Memory Stick PRO-HG Duo HX |
| Recording/Playback Time |
170 min (2h 50m) with 32GB Memory Stick PRO-HG Duo HX at FX(24Mbps) Linear PCM 2ch recording |
| Storage Temperature |
4 to +140 degrees F (-20 to +60 degrees C) |
| Video Recording Format |
HD: HD MPEG-4 AVCHD format compatible +1080/60p original format) SD: MPEG-2 PS (Same as DVD) |
| Dimensions (W x H x D) |
Body only: 5 x 4 x 7-5/8 inch (126.5 x 101.5 x 193.5 mm) |
| Weight |
Including lens and microphone: 6 lbs. 1oz (2.76 kg) |
