| Media Format |
Quick Format (Initialize): Memory Card |
| Camera Type |
Interchangeable Lens Digital HD Video Camera Recorder |
| Imaging Sensor |
Imaging Sensor: 35mm Full-Frame Exmor HD CMOS sensor (35.8 x 23.9mm) Processor: BIONZ Image processor Anti Dust: Charge protection coating on Filter Pixel Gross: Approx. 24.7 MP APS-C compatible mode: Yes (Auto/On/Off) Anti Dust: Charge protection coating on Filter Color Filter System: RGB Primary color filters Effective Picture Resolution: Approx. 24.0 MP (3:2 Still) / Approx. 20.3 (16.9 movie) |
| Flash |
Flash Type: Multi interface Shoe Flash Metering System: Pre-flash TTL Flash Modes: Auto/Forced/Slow Sync./Rear Sync./Prohibited Flash Compensation: Yes(+/-2EV , 1/3EV Step) |
| Drive System |
Shutter Type: Electronically-controlled, vertical-traverse, focal-plane type Shutter Speeds: Auto Control Range: 1/48-1/10000 (movie_24p) ,1/60-1/10000(movie_other)/ 30s-1/8000 (Still); Manual: 1/4-1/10000 (movie) , 30s-1/8000 (Still) Continuous Shooting Speed: 6fps Drive Mode: Photo Mode:Single-shot/Continuous/Bracket 0.3EV/Bracket 0.7EV Self-timer: Approx.10sec.(Still Image) |
| Picture Effects |
Movie and Still: Posterization, Pop color, Retro Photo, Partial Color, High constrast, Monochrome, Toy Camera; Still Only: Soft Focus, Miniature |
| Exposure |
Noise Reduction: Yes Gain Control: Auto/manual (0dB-30dB) WB Shift: Yes (G7-M7 15steps, A7-B7 15steps) Backlight Compensation: Yes (Auto) Color Temperature: Yes D-Range Optimizer: Yes Exposure Compensation: AE Shift (Dial/Touch Panel) Exposure Settings: Auto; Flexible Spot (Touch Panel); Manual (Dial) ISO: Still Mode Only - Auto,Manual (100 to 25600) Manual Exposure Assist : Zebra Pattern Display |
| Metering |
Metering: Still Mode Only: 99 Segment metering from CMOS image sensor Metering Modes: Still Mode Only: Multi-segment, touch spot Metering Sensitivity: Still Mode Only: EV-2 - 17EV ( at ISO100 conversion with F1.4 lens) |
| Minimum Illumination |
8 lux(1/60 Shutter Speed F3.5) |
| White Balance Mode |
Auto/Onepush/Outdoor/Indoor/WB Temp |
| Focus Control |
Focus System: Contrast AF Focal plane phase detection AF: Yes (Contrast AF Assist at Still & 24p movie Stand-by mode with several A-mount lens) Focus Area: Multi Point AF(25 points) Focus Features: Tracking Focus Focus Points: 25 points Manual Focus Assist: Magnified display for precise manual focus; Peaking Display |
| SD Output |
Composite Video Out (A/V connecting cable(supplied)); Component Video Out (Component A/V cable (supplied); S Video Out (A/V connecting cable with S Video (sold separately)) |
| USB Ports |
mini-AB/USB2.0 Hi-speed (mass-storage/MTP) |
| A/V Remote Terminal |
Video/S Video/Audio/Component Out/Remote |
| Accessory Shoe |
Multi interface Shoe |
| DC IN |
Yes |
| DVDirect |
Yes (DVD Writer supported(sold separately)) |
| Direct Copy |
Yes |
| HD Output |
HDMI (mini) |
| HDMI Terminal |
Yes (mini) |
| Headphone Jack |
Stereo Minijack |
| Memory Card Slot |
Single slot accepts: - Memory Stick PRO Duo/Pro-HG Duo/PRO-HG HX Duo media - SD, SDHC, and SDXC memory card |
| Microphone Input |
Stereo Minijack |
| PhotoTV HD |
Yes |
| Remote Terminal |
Integrated into A/V Remote terminal |
| Viewfinder |
Color Temp. Adjust: Yes Diopter Adjustment: Yes Field of View: 1 Type: Swivel EVF 1.3cm (0.5 type) 2359k dots |
| Still Image Mode |
JPEG/JPEG+RAW/RAW |
| Still Image Size 3:2 |
L (24.0M): 6000 x 4000 M (10.3M): 3936 x 2624 S (4.6M): 2640 x 1760 |
| Video Mode |
HD PS: Approx. 28Mbps FX: Approx. 24Mbps FH: Approx. 17Mbps HQ: Approx. 9Mbps LP: Approx. 5Mbps STD HQ: 9Mbps |
| Audio Format |
Dolby Digital 5.1ch, Dolby Digital 5.1Creator; Dolby® Digital 2ch stereo |
| Microphone/Speaker |
Built-in Microphone/Monoral Speaker |
| Mic Level Control |
Yes (31steps) |
| Media Type |
Memory Stick PRO Duo/Pro-HG Duo/PRO-HG HX Duo media SD, SDHC and SDXC memory card (both sold separately) |
| Photo Capture from Movie |
2.1 megapixels 16:9 (1920x1080), 307K pixels 4:3 (640x480), 230K pixels 16:9 (640x360) |
| Recording and Playback Times |
HD:60p/24p, Progressive recording |
| Still Image File Format |
DCF Ver.2.0 compatible, Exif Ver.2.3 compatible, MPF Baseline compatible |
| Still Image Max Effective Resolution |
24.0 megapixels |
| Still Image Size (Photo Mode) |
L (24.0M): 6000 x 4000 M (10.3M): 3936 x 2624 S (4.6M): 2640 x 1760 |
| Video Signal |
HD: HDTV 1080/60p, 24p, 60i; STD:NTSC color, EIA standards |
| Wind Noise Reduction |
Yes (Off/On) |
| Wind Position |
Yes (Auto) |
| Advanced Features |
Assignable Dial: Yes (Exposure/Gain(ISO)/Iris/Shutter Speed/AE Shift/WB Temp./WB B-A/WB G-M Set) Tracking Focus: Yes Audio Level Display: Yes CinemaTone Gamma/Color: Yes x.v.Color: Yes Face Detection: Yes (Auto/Child Priority/Adult Priority) Priority Setting (for Face Detection): Auto/Child Priority/Adult Priority View & Index: Event |
| Convenience Features |
Quick On: Yes Self Timer: Approx. 10sec.(Still Image) Red-Eye Reduction: Yes(On/Off) Date / Time Stamp: Yes (Rec Date and Time, Camera info) View & Index: Event One Touch Disc Burn: Yes (Menu) S/S & Zoom button on LCD: Yes(Touch Panel , S/S Only) Still Image Playback Options: Slide Show |
| Optics/Lens |
Digital Zoom: Yes (x2.0) |
| Software |
Supplied Software: Vegas Movie Studio HD Platinum 11 included via download to PC4 |
| LCD Display |
Angle Adjustment: Opening Angle - max.90 deg., Turning Angle - max.270 deg Brightness Control: Yes (Menu) Coverage: 1 Grid Display: Yes (On/off) Histogram: Yes LCD Type: 3.0 Xtra Fine LCD 270 degree swivel display Live View: Yes, (Constant AF Live View) Real-time image adjustment display: Exposure Compensation, WB Touch Panel: Yes |
| Zoom Control |
Digital Zoom: Yes(×2.0) Power Zoom Control: Yes Zoom Lever: Yes Zoom Speed: Variable/Fix max 32 Steps |
| Face Detection |
Auto Control: Yes Face Touch: Yes |
| Digital Picture Effects |
Movie and Still: Posterization, Pop color, Retro Photo, Partial Color, High constrast Monochrome, Toy Camera; Still Only: Soft Focus, Miniature |
| Erase/Protect |
Yes/Yes |
| Manual/Auto Lens Cover |
Manual |
| Media/Battery Indicator |
Yes (recordable time, free and used media space)/Yes (recordable time, remaining capacity) |
| Multiple Language Display |
English, Simplified English, Brazilian Portuguese, Canadian French, Latin American Spanish |
| Battery Type |
InfoLITHIUM with AccuPower Meter System (V Series) NP-FV70/FV100 |
| Charge on Camcorder Time |
Approx. 3h 15 min with supplied battery |
| Power |
Power Consumption (in Operation): HD:4.7W; STD:4.5W Power Consumption (in View Finder Operation): HD:5.2W; STD:5.0W Power Requirements: 7.2V (battery pack); 8.4V (AC Adapter) |
| Dimensions WxHxD |
4.3 x 5.1 x 8.9" (109 x 130 x 226mm) with supplied NP-FV70 battery |
| Weight |
1.8 lbs (825g) with supplied NP-FV70 battery |
