5 x 1 AV switcher contains 2-RGB/component video inputs and 3-composite video inputs (each with stereo audio) |
|
Integrated high quality audio mixer with 4-microphone and 1 stereo line input |
|
Mounting slots built in for two (optional UTX-M2) wireless mic diversity receiver modules |
|
Audio signal processing includes digital equalizer and dynamics processing for each microphone channel, plus on-board digital feedback reducer |
|
Built-in 4ch digital power amplifier |
|
Scene storage, plus last memory recall |
|
RS-232C and parallel input ports for remote control from a PC, third party system controller or control panel |
|
RS-232C output port for remote control of applicable video/data projector or plasma display panels |
|
PC setup software supplied |
|
All-in-One Design: It integrates the functionality of seven devices to manage today's modern presentation system. The 7 key functions include; RGB Switcher, Video Switcher, Wireless Tuner Base Unit, Audio Mixer, Power Amplifier, Feedback Reducer and Equalizer |
|
High Quality Digital Processor: The SRP-X500P is equipped with digital feedback reduction function for each microphone input channel. It can be enabled to seek out the frequency, in which howling is likely to occur and suppress the howling by reducing the amplifier gain with 5 band equalization |
|
Enhanced User-Friendly System Presets: The SRP-X500P supports various AV system configurations without any meticulous manual adjustments, by selecting a System type from the nine system presets |
|
Versatile Interface: The SRP-X500P is equipped with three composite inputs and two RGB/Component inputs. The SRPX500P supports high-resolution component signals such as 480p and 1080i and also SXGA (1280 X 1024 pixels) for RGB |
|
Integrated Wireless Mic Tuner Slots: Up to two optional wireless tuner modules, the UWP-X7/X8 series or the WRU-806 can be directly installed in the SRP-X500P, making it simple to integrate a high quality Sony wireless microphone system into the presentation system |
|
Comprehensive Remote Control: The SRP-X500P provides extensive control capabilities through its Control-S, RS-232C and parallel port or an optional RM-AV3000 series Wireless Remote Commander |
|
Built-in Four-Channel Digital Power Amplifier: The SRP-X500P is equipped with four-channel digital power amplifiers that can be switched between high and low impedance modes corresponding to various loudspeaker and room types |
|
Easy-to-Use GUI: The SRP-X500P Manager program allows easy configuration of the system during installation, including control of audio processing settings, such as equalizer, AGC and compressor using a simple and intuitive GUI |
| Audio Inputs | Phono Jack Circuit: Unbalanced Reference Input Level: -60 to -30 dBu Max Input Level: +10 dBu |
| Audio Outputs | Phono Jack Impedance: 10 K ohm Reference Level: -5 dBu Maximum Level: +15 dB Impedance: 10 K ohm or more |
| Video Inputs | Phono Jack HD D-sub, 15-pin |
| Video Outputs | Phono Jack |
| Output Impedance | 10 K ohm or more |
| Total Harmonic Distortion | Less than 0.01% |
| Operating Temperature | 32 to 104 Degrees F |
| Storage Temperature | -4 to 140 Degrees F |
| Frequency Response | 10Hz to 20KHz +/-0.5dB |
| Microphone Connector | XLR-3-31 type Circuit: Balanced Reference Input Level: -60 to -30 dBu Max Input Level: -37 to -7 dBu |
| Audio S/N Ratio | 94 dB or more (LINE OUTPUT, IHF-A) |
| Component/RGB Frequency Response | 50 Hz to 150 MHz, 480i,1080i, supports 1280 x 1024 60Hz (SXGA) |
| Microphone Power Supply | Antenna In A/B Connectors, BNC-type, Supplies +9 V DC, +48 V Power Supply |
| Remote Connector | RS-232C, D-Sub 9-pin (male) Mini Jack D-Sub, 25-pin (female) |
| Power Requirements | AC 120V |
| Power Consumption | 120 W |
| Dimensions | 19 x 5 1/4 x 14 inches |
| Weight | 26 lb. 3 oz. |
| Warranty | Sony warranty |
| | |
