| Projector Display System |
3 LCD System Size of effective display area 0.99" (25mm) x 3 |
| Native Resolution |
1024 x 768 |
| Number of Pixels |
2,359,296 (1024 x 768 x 3) Pixels |
| Brightness |
7000 Lumens (Lamp mode: High) 5600 Lumens (Lamp mode: Standard) |
| Contrast Ratio |
2500:1 |
| Aspect Ratio |
4:3 |
| Scan Frequencies |
Horizontal: 14 to 93 kHz Vertical: 47 to 93 Hz |
| System |
NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60 |
| HDTV Compatibility |
480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p |
| Focus/Zoom Adjusting |
Zoom Powered / Manual (Depend on lens) Focus Powered / Manual (Depend on lens) |
| Lens Shift |
Powered |
| Recommended Projection Size |
40 to 600" (1.02 to 15.24 m) |
| Keystone Correction |
Vertical: Max. +/- 30 degrees |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Projection Tilt Option |
Yes |
| Inputs/Outputs |
S-Video In x 1 Composite Video In x 1 Analog RGB/Component In x 1 Component In x 1 Digital In x 1 NetworkRJ-45 x 1 Monitor Out x 1 RS-232C x 1 Stereo Mini Jack x 1 |
| Lamp (Bulb) |
330W type (Twin Lamp System) 6000 Hours (Lamp Mode: High) 8000 Hours (Lamp Mode: Standard) |
| OSD Language |
20 Languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Vietnamese, Arabic, Persian) |
| Remote Control |
Yes |
| Operating Temperature |
32 to 104deg.F (0 to 40deg.C) |
| Storage Temperature |
-4 to +140deg.F (-20 to +60deg.C) |
| Operating Humidity |
35 to 85% (no condensation) |
| Storage Humidity |
10 to 90% |
| Power Requirements |
AC 100 to 240 V, 4.8 to 2.0 A, 50/60 Hz |
| Power Consumption |
AC 100 to 120 V: 480W AC 220 to 240 V: 460W Standby Mode: AC 100 to 120 V: 13W (Standby Mode: Standard) / 0.1W (Standby Mode: Low) AC 220 to 240 V: 12W (Standby Mode: Standard) / 0.2W (Standby Mode: Low) |
| Heat Dispersion |
AC 100 to 120 V: 1638 BTU AC 220 to 240 V: 1570 BTU |
| Regulations |
UL60950-1 2nd Edition, cUL (No. 60950-1 2nd Edition), FCC/IC Class A, CE EN60950-1 2nd Edition (LVD, EMC), C-Tick, JIS C 61000-3-2, GOST-R |
| Dimensions (W x H x D) |
20.9 x 8.4 x 21.5" (530 x 213 x 545mm) |
| Weight |
44.1 lb. (20kg) |
