The Schneider Optics offers a circular True-Pol Polarizing filter for cameras which use polarizing elements in the beam-splitters of the viewing system, such as ARRI 435 and the Movie-Cam Compact. This filter may also be required on certain high definition video cameras with complex optical blocks such as the Sony PMW-EX1, PMW-EX3 and PDW-700 which polarize the red an blue channels more than other cameras and therefore require a circular polarizer to prevent cross polarization and associated color shift in the image. Beam splitters send light in two directions: to an eye-piece and to a video tap.
Light in a camera's viewing system can become polarized and when a standard (linear) polarizing filter is attached to the lens, the light becomes cross polarized. This hinders visibility and may create total black-out of the viewing image and/or the video tap. Schneider Optics Circular Polarizers feature a two layer design to prevent this blackout. The first layer is made up of the same polarizing material used in all True-Pol filters; the second layer is a 1/4- wave retarder plate which effectively prevents cross-polarization.
|Filter type||Circular True-Polarizer|
|Filter Factor||Between 2.3 and 2.8 (approx. +1.3 stops)|
|Effect||Removes reflections and increases color saturation without affecting the overall color balance|
|Application||Nature, travel, outdoor photography|
|Construction||Water White Schott Glass|
|Dimensions||4 x 5.65" (100 x 140mm, 4mm thick)|
