| DVR: Functionality |
Pentaplex |
| DVR: Video Compression |
H.264 |
| DVR: Audio Compression |
G.711 |
| DVR: Number of Channels |
8 |
| DVR: Video Input |
4/8 x BNC |
| DVR: Video Output |
2 x BNC
VGA |
| DVR: Audio Input |
2 x RCA |
| DVR: Audio Output |
1 x RCA |
| DVR: USB Port |
2 |
| DVR: Resolution |
800x600, 1024x768, 1280x1024 |
| DVR: Recording Total Frame Rate |
NTSC:60fps@D1 120fps@HD1 120 fps@CIF
PAL:50fps@D1 100fps@HD1 100fps@CIF |
| DVR: Recording Frame Rate Per Channel |
NTSC: 1fps-30fps adjustable
PAL: 1fps-25fps adjustable |
| DVR: Recording Resolution |
NTSC : D1(704 X 480), HD1(704 X 240), CIF(352 X 240)
PAL: D1(704 X 576), HD1(704 X 288), CIF(352 X 288) |
| DVR: Recording Modes |
Motion Record, Schedule, Always |
| DVR: Pre Recording |
Max 10 seconds |
| DVR: Post Recording |
Max 5 minutes |
| DVR: Recording Media |
HDD (Backup via USB) |
| DVR: Storage Capacity |
Max 1TB HDD |
| DVR: HDD Type |
SATA 3.5" |
| DVR: Storage Capacity |
Max 1TB (HDD) |
| DVR: Video Format |
NTSC/PAL |
| DVR: Video Loss Alarm |
Auto Detect Alarm |
| DVR: Audio Bitrate |
8 kbps |
| DVR: Live Frame Rate |
30 FPS |
| DVR: Live Viewing |
Full, Quad, PIP, ZOOM, SEQ |
| DVR: Picture-in-Picture |
Yes |
| DVR: Network Protocol |
TCP/IP, DDNS, DHCP, PPPoE,UDP |
| DVR: Network LAN IP |
Static, Dynamic |
| DVR: Network Connection |
10/100 BaseT Ethernet (RJ-45) |
| DVR: Supported Operating Systems |
Windows XP, Windows Vista, Windows 7, OSX 10.5 or above |
| DVR: Browsers |
Internet Explorer, Safari |
| DVR: Back-up |
USB Flash drive, USB disk & network |
| DVR: Play Search Mode |
Time/Date, Event list |
| DVR: Play Speed |
2x, 4x, 8x, 16x |
| DVR: Pan/Tilt/Zoom |
RS-485 Pelco D & P |
| DVR: OSD Language Display |
Multi-Language |
| DVR: Time and Date Stamp Display |
Yes |
| DVR: Password Protection |
Yes, Menu Password, Clear HDD Password |
| DVR: Operating System |
Linux |
| DVR: Processor |
ARM 9 |
| DVR: Disk Full Warning |
Yes |
| DVR: Automatic Overwrite Option |
Yes |
| DVR: LED Indicators |
Power, HDD |
| DVR: Housing Material |
Aluminum |
| DVR: Power Input |
12V DC 3A |
| DVR: Power Consumption |
10W-15W |
| DVR: Power Adapter Input |
100V 50/60HZ-240 50/60HZ |
| DVR: Operating Temperature |
32 deg.F-104 deg.F |
| DVR: Operating Humidity |
10%-90% |
| Camera: Image Sensor |
1/3" CMOS |
| Camera: Resolution |
600 TVL |
| Camera: Outdoor Use |
Yes |
| Camera: IP Rating |
IP65 |
| Camera: Focal Length |
5mm |
| Camera: Focus Type |
Fixed |
| Camera: Optimal Focal Distance |
20 ft. |
| Camera: Night Vision |
Yes |
| Camera: Number of IR LEDs and Range |
36 |
| Camera: Night Vision Range |
100 ft. |
| Camera: IR LED Control |
Automatic (CDS Sensor) |
| Camera: Min. Illumination |
0 lux |
| Camera: IR Wavelength |
850nm |
| Camera: Video Output |
BNC/DC |
| Camera: TV System |
NTSC |
| Camera: Viewing Angle |
60 Degrees |
| Camera: Electronic Shutter |
1/60 - 1/100000 sec |
| Camera: AGC |
Automatic |
| Camera: ELC |
Automatic |
| Camera: Gamma Correction |
>0.45 |
| Camera: White Balance |
Automatic |
| Camera: Sun Shield |
Yes |
| Camera: IR Cut Filter |
Yes |
| Camera: Housing Material |
Anodized Aluminum |
| Camera: Signal/Noise Ratio |
>48dB |
| Camera: Camera Bracket |
Yes, anti-vandal |
| Camera: Operating Temperature |
-10° - 60°C / Degrees |
| Camera: Operating Humidity |
98% |
| Camera: Camera Power Input |
DC 12V 300mA |
| Camera: Power Adapter Input |
120V 60Hz |
| Dimensions |
DVR: 8.75 x 11 x 2" / 222 x 279.4 x 50.8 cm
Camera: 6.75 x 3 x 5.5" / 171.4 x 76.2 x 139.7 cm |
| Weight |
DVR: 3.75 lbs (1.70 kg)
Camera: 0.9 lbs (0.40 kg) |
