Starlight Xpress Trius SX-35 Large Format Interline Monochrome CCD Camera, USB 2.0, 9uMx9uM Pixel Size, 4032x2688 Pixels Image Format

SKU: SXTSX35 MFR: TRIUSSX-35

Our Price

$5,032.99
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

Availability: Special Order .

Free Shipping

See all shipping options

Starlight Xpress Trius SX-35 Large Format Interline Monochrome CCD Camera, USB 2.0, 9uMx9uM Pixel Size, 4032x2688 Pixels Image Format $5,032.99

About Starlight Xpress SXVR-H35

The Starlight Xpress SX-35 is the largest in the SX line of Kodak CCD based imagers. To reduce the negative effects of the greater Kodak dark signal, Starlight Xpress has used a two stage Peltier cooler for an extra 10 degree reduction in the CCD temperature and a new high-speed USB 2.0 interface circuit to greatly reduce the download time. The fast download minimizes the visibility of bias frame artefacts, such as hot columns and the top to bottom gradient that is commonly seen on such chips.

When you choose a Starlight Xpress SX-35, you choose to get a large, high resolution Kodak CCD chip, with 10,838,016 x 9uM square pixels in a 36.3 x 24.2mm array. This means you want high sensitivity, with approximately 52% quantum efficiency at peak (green light), 31% at H alpha. The SXVR-H35 offers up a low dark signal - which means dark frames aren't necessary for most of the brighter deep sky objects. By choosing a Starlight Xpress SXVR-H35, you're also choosing to have anti-blooming with minimal effect on linearity and no lost active area.

The Starlight Xpress SX-35 offers built-in super high speed USB 2.0 interface for approximately 7 second downloads, a built-in autoguider interface and output - compatible with the optional dedicated external guide camera, a built-in dual serial ports for accessory control to directly drive filter wheels, GOTO telescopes etc. Your computer knows what that means... It means a single USB cable control for all features! No mo re Medusa in the control room... and no un-needed power consumption!

Starlight Xpress SXVR-H35 Features

  • Built-in autoguider interface and output - compatible with the optional dedicated external guide camera
  • Built-in dual serial ports for accessory control - directly drive filter wheels, GOTO 'scopes etc
  • Single USB cable control for all features - get rid of that dangerous cable tangle!
  • Only ONE computer needed to control all of the devices and functions
  • Very low power consumption. Less than 1.0 amps at 12v DC - 12VA at 110v or 240v AC
  • Compact and lightweight - only 118mm in diameter x 102mm long - less than 1100 grams load on the telescope
  • 72 x 1mm input thread, compatible with Takahashi FSQ106 etc

Starlight Xpress SXVR-H35 Specifications

CCD type
Kodak KAI11002M interline CCD with low dark current and vertical anti-blooming.
CCD Full resolution Pixel data
Pixel size: 9uM x 9uM, Image format: 4032 x 2688 pixels
CCD Image area
36.3mm (Horizontal) x 24.2mm (Vertical).
CCD quality
Grade 2 as standard.
Spectral Response
QE max at 540nM (-52%), 30% at 400nM and 660nM.
Readout Noise
Less than 15 electrons RMS - typically only 12 electrons.
Full-well capacity
Greater than 50,000 e- (unbinned)
Anti-blooming
Overload margin greater than 1000x.
Dark current
Dark frame saturation time greater than 10 hours. Less than 0.08 electrons/second @ + 10C ambient.
Data format
16 bits.
System gain
0.9 electrons per ADU
Computer Interface
Built-in USB 2.0 compatible interface.
Image download time
Typically 7 seconds at full resolution using USB 2.0.
Power requirements
115VAC / 240VAC @ 12VA, or 12VDC @ 750mA max.
Cooling system
Regulated constant current cooling supply with two stage thermoelectric cooler to give a CCD temperature of approximately -40C below ambient.
Size
98 x 100mm / 3.85 x 3.93" black anodized aluminium barrel with 72 x 1mm / 2.83 x 0.039" thread at the CCD window end & input/output plugs at rear. CCD alignment screws are provided for setting the chip parallel to the focal plane.
Weight
Approx. 1100g /3.52oz
Mfr #
TRIUSSX-35
SKU
SXTSX35
