| CPU Frequency |
1.6 GHz |
| Engine |
Hardware Encrypted |
| Memory |
256 MB DDR3 |
| Internal HDD/SSD |
1x 3.5" (88.89 mm) or 2.5" (63.49 mm) SATA II (Hard drive not included) |
| Maximum Internal Capacity |
4 TB (1x 4 TB HDD) (Capacity may vary by RAID types) |
| System Fan |
One 2.36 x 2.36" (60 x 60 mm) |
| External HDD Interface |
2x USB 3.0 port, 1x eSATA port |
| LAN |
1x Gigabit |
| Power Saving |
Wake on LAN / WAN |
| Wireless Support |
Yes |
| Noise Level |
18.4 dBA |
| Power Recovery |
Supported |
| AC Input Power Voltage |
100 to 240 V |
| Power Frequency |
50 - 60 Hz, Single Phase |
| Power Consumption |
13.2 W (Access); 5.04 W (HDD Hibernation) |
| Certifications |
FCC Class B, CE Class B, BSMI Class B |
| File Station |
Virtual drive
Remote folder |
| Backup Solution |
Network backup
Local backup
Desktop backup (Windows: Synology Data Replicator 3, Mac: Apple Time Machine backup application)
Shared Folder Sync - Max Task Number: 2
LUN Backup - Max Task Number: 2
Configuration backup |
| Mail Server |
Supported Mail Server Protocol: POP3, SMTP, IMAP |
| FTP Server |
Bandwidth control, custom FTP passive port range, anonymous FTP, transfer log |
| Web Station |
Virtual host (up to 30 websites)
PHP/MySQL
Third party applications support |
| Print Server |
Max Printers: 2
Printing Protocols: LPR, CIFS, AppleTalk, Apple AirPrint, Google Cloud Print, Multi Functional Print Server (For Windows PC only) |
| iOS/Android Applications |
DS photo+
DS audio
DS cam
DS file
DS finder |
| Windows Phone Applications |
DS finder |
| Networking Protocols |
CIFS
AFP
NFS
FTP
WebDAV
iSCSI
Telnet
SSH
SNMP
VPN (PPTP, OpenVPN) |
| File System |
EXT4
EXT3(external disk only)
FAT (external disk only)
NTFS (external disk only) |
| Storage Management |
Max File System Size: 16 TB
Max Internal Volumes: 1
Max iSCSI Targets: 10
Max iSCSI LUNs: 10
Supported RAID Type: Basic |
| File Sharing Capability |
Max User Accounts: 2048
Max Groups: 256
Max Shared Folder: 256
Max Concurrent CIFS/AFP/FTP Connections: 128 |
| Windows Access Control List (ACL) |
Supported |
| Windows ADS Domain Integration |
Domain users login via Samba/AFP/FTP/File Station |
| Backup Solutions |
Network backup
Local backup
Desktop backup (Windows: Synology Data Replicator 3, Mac: Apple Time Machine backup application)
Shared Folder Sync (Max Task Number): 2
Configuration backup |
| Security |
FTP over SSL/TLS
IP auto-block
Firewall
Encrypted network backup over Rsync
HTTPS connection |
| Management |
Auto DSM upgrade
Administrator group
Push Notification MSN/Skype/mobile devices
Email/SMS notification
Customized user quota
Syslog support
DDNS support
IPv6 support
VLAN support
PPPoE
Hotspot
Resource monitor
Connection manager
UPS management
Scheduled power on/off
Custom management UI HTTP/HTTPS ports |
| HDD Management |
HDD hibernation
S.M.A.R.T.
Dynamic bad sector mapping |
| Utilities |
Synology Assistant
Synology Data Replicator |
| Supported Clients |
Windows XP onward
Mac OS X 10.5 onward
Ubuntu 9.04 onward |
| Supported Web Browsers |
Chrome
Firefox
Internet Explorer: 8, 9
Safari (Mac): 5 |
| Languages |
Czech, Danish, Dutch, English, French, German, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese Brazil, Portuguese European, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish |
| Operating Temperature |
41 - 95deg.F (5 - 35deg.C) |
| Storage Temperature |
15 to 155deg.F (-10 to 70deg.C) |
| Relative Humidity |
5 to 95% RH |
| Maximum Operating Altitude |
10,000' (3048 m) |
| Environment |
RoHS compliant |
| Performance |
Windows Upload / Download (5 GB file):
Windows Upload: 71.84 MBps
Windows Download: 110.19 MBps
Windows Upload / Download (1 MB x 5000 files):
Windows Upload: 42.46 MBps
Windows Download: 65.41 MBps
AES 256-bit Encrypted File Upload / Download (5 GB file):
Windows Upload: 13.15 MBps
Windows Download: 23.34 MBps
iSCSI Write / Read (5 GB file):
Windows Upload: 56.20 MBps
Windows Download: 64.13 MBps
Web Server Responsiveness (1000x requests):
Seconds: 142.35 |
| Dimensions (HxWxD) |
6.53x2.79x8.81" (166x71x224 mm) |
| Weight |
1.58 lb (0.72 kg) |
