Teradek Cube-500 1 Channel Composite Encoder, Ethernet and External USB Port

Teradek
SKU: TECUBE500 MFR: 10-0500
Free Shipping

See all shipping options

Special Order Item - This is a special order item that is Non Cancelable and Non Returnable. We Charge you when you place your order. Approximate arrival at Adorama 1-2 Weeks from date of order. learn more

Made in USA

Our Price

$999.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About Teradek Cube-500

The Teradek Cube-500 1-Channel Composite Encoder streams composite video directly from your camera to a Cube decoder, computer, laptop, server, or a mobile device such as an iPad, over a wired Ethernet. H.264 High Profile (Level 4.1) video compression helps reduce video file sizes without compromising on the quality and integrity of images. The Cube 500 Encoder supports 480i/576i input resolutions. Downscaling to lower resolutions is possible via a built-in scaler that allows for output streaming at 240p resolution. Moreover, users can select the resolution and target bit rate according to the available IP bandwidth.

Lightweight construction and compact size lets you mount the encoder on several cameras including RED ONE, ARRI Alexa, Panavision Genesis, Canon 5Dii and Canon 7D. By using its own wireless (ad hoc) network for transmission, the encoder does not require any additional networking equipment. Furthermore, it can stream over a LAN or WAN using a wireless router by joining an infrastructure network.

The Cube 500 encoder features a Setup Wizard that helps simplify configuration. To begin streaming video, simply provide video and power inputs, create a network, logon to Cube's web interface and complete the Setup Wizard.

Native integration with Livestream makes the Cube 500 suitable for turnkey (ready for immediate use) video streaming. Enter your Livestream account information into Cube's user interface, zero in on a broadband uplink and you are all set to begin broadcasting. While using Livestream, upload/download speeds of 8 Mbps have been achieved on the Verizon 4G LTE network in the Los Angeles and New York metro areas.

Using a single Verizon 4G modem connected to the optional USB port, the encoder can stream videos to Livestream. This allows the encoder to be used as a backup Internet connection or even as a mobile wireless live streaming camera.

Teradek Cube-500 Features

  • Streams composite video directly from your camera to a Cube decoder, computer, laptop, server, or a mobile device such as an iPad, over a wired Ethernet connection
  • Creates its own wireless (ad hoc) network for transmission and does not require any additional networking equipment
  • Streams over a LAN or WAN using a wireless router by joining an infrastructure network
  • 480i / 576i input resolutions
  • Allows you to configure the resolution and target bit rate according to the available IP bandwidth
  • Setup Wizard helps simplify configuration - To begin streaming video, simply provide video and power inputs, create a network, logon to Cube's web interface and complete the Setup Wizard
  • Upload / download speeds of 8 Mbps have been achieved while using Livestream on the Verizon 4G LTE network in both the Los Angeles and New York metro areas
  • Using a single Verizon 4G modem connected to the optional USB port, the encoder can stream videos to Livestream, allowing the encoder to be used as a backup internet connection or even as a mobile wireless live streaming camera
  • H.264 High Profile (Level 4.1) video compression helps reduce video file sizes without compromising on the quality and integrity of images
  • Downscaling to lower resolutions is possible via a built-in scaler that allows for output streaming at 240p resolution
  • Compact (2.5 x 3.5 x 1" / 6.35 x 8.89 x 2.54 cm) and lightweight (0.44 lb / 0.22 kg) construction allows it to be mounted on several cameras including RED ONE, Arri Alexa, Panavision Genesis, Canon 5Dii and Canon 7D
  • Enter your Livestream account information into Cube's user interface, zero in on a broadband uplink and you are all set to begin broadcasting
  • Power efficient - uses only 2.5W DC power
  • Low latency (250 ms) ensures faster performance

Teradek Cube-500 Specifications

Supported Resolutions
480i (NTSC)
576i (PAL)
Video Codec
Compression Algorithm: High Profile H.264 (L4.1)
Bit Rate: 250 Kbps to 10 Mbps
Network
Ethernet: 10/100BASE-T
Network Protocols: TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP
Transport Protocols: RTP, RTSP, RTP over HTTP, MPEG-TS
HTTP Live Steaming
Feature-rich WebUI for configuration and control
Point to Point (TCP or UDP), Multiple Unicast (UDP), or Multicast (UDP+IGMP)
Audio
Embedded Stereo
Audio Compression: AAC-LC, MPEG Layer 2
Line or Mic in
Interfaces
Powered USB 2.0 Port
Nominal Power Consumption
2.5W - 3.8W
Auxiliary Power Input
6-28V DC
Temperature
0 to +50deg. C
Humidity
95% non condensing
Dimensions (W x D x H)
2.5" x 3.5" x 0.9" / 63.5 x 88.9 x 22.86 mm
Weight
7 oz / 198.45 g
