| Processor |
Intel Celeron-M Technology |
| SATA Controller |
8xSATA for internal, 1xeSATA for external |
| System Memory |
2GB DDR2 SDRAM |
| LAN Interface (PCI-e) |
RJ-45x2: 10/100/1000 BASE-TX Auto MDI/MDI-X WOL supported |
| USB Interface |
USB 2.0 host port x4(Front x2, Back x2) (A Type) |
| LCM |
Displays system status and information |
| LED indicator |
Power:(Yellow) System alert: Redundant power or system fan failure (Red) HDD1-8 Activity/Fail(Green/Red) |
| PCI-e x 8 slot |
1 |
| Power supply |
350W Redundant Power Supply |
| Disk interface |
SATA x8 via backplane |
| Thermal/Fan control |
Thermal sensor on processor temperature |
| System Fan |
4 x Hot Swappable |
| Buttons |
Power button(Front, power down controlled by S/W) LCM button (ENT,ESC,UP, DOWN) System reset button Mute button while system alert |
| RS232 |
1 (For UPS) |
| Temperature |
5 Deg.C to 40 Deg.C |
| Humidity |
0 - 80 % R.H. (Non-condensing) |
| RAID modes |
RAID 0, 1, 5,6,10,JBOD |
| Auto-rebuild |
Supported |
| Hot-swap |
Supported |
| Hot spare |
Supported |
| SMART Info |
Supported |
| SMART Test |
Supported |
| On line RAID Migration |
Supported |
| On line RAID Expansion |
Supported |
| RAID Volume Encryption |
AES256bit |
| Power management |
Spin down while idle time setup |
| Bad Block Scan |
Supported |
| Disk Roaming |
Supports roaming to other N8800+ |
| Configuration |
Fixed IP Address, Dynamic IP Address |
| IP sharing mode |
Can be enabled / disabled |
| Transport Protocols |
TCP/IP/Appletalk |
| File Protocols |
SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP |
| Link Aggregation |
802.3ad, load balance and fail over, Balance-XOR, Balance-TLB, Balance-ALB |
| Data Access: Client OS support |
Windows 2000/XP/2003/Vista/7 UNIX/Linux Mac OS 9 / X |
| Data Access: WebDisk |
Web-based file access |
| Data Access: FTP |
Build in FTP Server with bandwidth control |
| Data Access: Secure FTP |
Build in secure FTP Server with bandwidth control |
| Data Access: Download Manager (Module) |
HTTP / FTP / BT / eMule |
| Data Access: Printer Server (IPP) |
Supports USB printers Supports IPP various printers Client can manage print tasks (List/Delete) via Web user interface |
| Client data backup |
Acronis True image(OEM version) |
| Client system Disaster Recovery |
Acronis True image(OEM version) |
| NAS Remote Replication |
Via Thecus proprietary Nsync |
| USB device copy to N7700+ |
Through LCM to control |
| Snapshot |
Supported |
| Bi-directional USB Copy (Module) |
Supported |
| iSCSI Target |
Supports Microsoft/Mac/Linux Initiator |
| iSCSI initiator |
For stackable with N0503/1U4500/IU4600/N5200/N5500/N7700 series and N8800 series |
| iSCSI Thin Provisioning |
Virtual size adjustable up to 16TB |
| Schedule power on/off |
Supported |
| Multiple RAID |
Supported |
| Selectable file system |
Ext3 / XFS / ZFS |
| iTunes Server |
Supported File Types: AAC, MP3 w/ ID3 tag, WAV |
| Photo Web Server |
Supported File Types: GIF, JPG (JPEG), BMP, PNG Supports EXIF display Supports slide show |
| Media server |
Supports uPnP AV streaming protocol |
| User Authentication: Local User |
Supports built-in user accounts |
| User Authentication: Local Group |
Supports built-in user groups |
| User Authentication: Windows NT/ADS |
Supported |
| File System Type |
Journaling File System |
| Capacity |
16TB (XFS,ZFS) / 8TB (ext3) per volume |
| Language Support |
Unicode Support |
| Authorization (ACL) |
Read, Write or Deny options on individual users or groups for share and sub-folders |
| Multi-Lingual Web-based administration |
Web-based server management Interface Supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian and Polish |
| Utility Program |
MS Windows Setup Wizard, supports Windows 2000/XP/2003/Vista/7 Mac setup Wizard (OSX only) |
| Email notification |
Sends system messages via Email to system administrator |
| SNMP trap |
System information trap out |
| Dual DOM |
Supported |
| Web Disk |
Supported |
| Recycled bin |
Supported |
| Web Server (Module) |
Supported |
| ISO Mount |
Supported |
| User module |
Supported |
| IP CAM surveillance (Module) |
Supported |
| Supported Web Browsers |
Internet Explorer 7 or higher Firefox 3 or higher Safari 4 or higher Google Chrome 4 or higher |
| Dimensions (W x H x D) |
16.9 x 3.4 x 23.6" (43 x 8.7 x 60cm) |
