| Frequency compatibility |
50 / 60 Hz |
| Output watts |
1800W |
| Circuit Breaker |
15 amps |
| Outlet quantity / type |
7 NEMA 5-15R |
| Transformer accommodation |
Supports 3 large transformer plug accessories without covering remaining outlets, accepts up to 5 transformers total |
| Outlet orientation |
Single row of 5, plus 2 side mounted outlets |
| Nominal Input Voltage(s) Supported |
120V AC |
| Recommended Electrical Service |
120V (110-125V) |
| Input connection type |
NEMA 5-15P |
| Input cord length |
12 ft / 3.65m |
| Input cord gauge, type |
14 gauge, SJT |
| Voltage compatibility |
120 VAC |
| Maximum Surge |
72000 Amps |
| Switches |
Two position on/off power switch |
| Diagnostic LEDs |
Built-in LED confirms suppressor "protection present" (green) status |
| AC suppression joule rating |
1080 |
| AC suppression response time |
< 1 ns |
| Protection modes |
Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression |
| Clamping voltage |
150V (RMS) |
| UL1449 let through rating |
330V - UL Verified |
| EMI / RFI filtering |
Up to 20 dB |
| Telephone/DSL Protection |
Yes |
| Telephone/DSL Protection Details |
1 line |
| Cable (Coax) Protection |
No |
| Network (Ethernet) Protection |
No |
| Dimensions (HxWxD) |
1.54x2.72x10.3" / 3.9x6.90x26.16cm |
| Weight |
1.82 lbs / 0.82kg |
