| Video Output |
Power input; Audio/Video output (NTSC or PAL selectable); Digital terminal (USB/Remote Cord) |
| Image sensor |
1/1.8-inch-type (total pixels: 5.26 million) |
| Lens |
4x Zoom-Nikkor; 5.8-24mm [35mm (135) format equivalent to 28-116mm] f/2.8-4.6 with macro; 9 elements in 8 groups (one ED lens and two aspherical lenses are used); all elements are made of environmentally friendly glass; Nikon Super Integrated Coating (SIC) applied / Aperture 6-blade iris diaphragm; 10 steps in 1/3 EV i ncrements |
| Digital Zoom |
Up to 4x |
| Optical viewfinder |
Real-image zoom viewfinder; Diopter adjustment: -3 +1m-1 |
| LCD monitor |
1.5-inch type, 134,000-dot highly transmissible advanced TFT-LCD (white LED backlight); brightness/hue adjustment; frame coverage: approx. 97% (Through, Freeze), 100% (Play) |
| Autofocus method |
Contrast-detect TTL AF; 5-area Multi AF or Spot AF selectable |
| Focusing range |
50cm (19.7 in.) to infinity / 1cm (0.4 in.) to infinity in Macro mode |
| Shutter speeds |
Mechanical and charge-coupled electronic shutter; 1/4,000 (with minimum aperture) to 1 sec. in AUTO mode and Programmed Auto [P]; 1/4,000 to 8 sec. in Shutter-Priority Auto [S] and Aperture-Priority Auto [A], 1/4,000 to 8 sec. and Bulb/Time (up to 10 minutes) in Manual [M], 1/8,000 to 1/30 sec. in Ultra HS (high-speed) mode |
| Exposure control methodá |
1) Programmed Auto with Flexible Program [P], 2) Shutter-Priority Auto [S], 3) Aperture-Priority Auto [A], 4) Manual [M]; Exposure Compensation (±2 EV in 1/3 EV steps); Auto Exposure Bracketing (3 or 5 frames within ±2 EV); AE-BSS (three modes: Highlight, Shadow, Histogram) |
| Continuous drive |
Capture modes 1) Single,2)Continuous H (3 fps; up to 7 frames),3)Continuous L (1.5 fps; up to 18 frames), 4) Multi-shot 16(consecutive 16 frames at 2 fps),5) Ultra HS (high-speed) (QVGA-size images; 30 fps; number of frames selectable, up to 100 frames),6)5 shot buffer(1.(1.5 fps),7)Movie with audio: TV movie mode (VGA -size images,640 x 480 pixels) at 15 fps; up to 70 sec., or Small movie mode (QVGA-size images, 320x240 pixels)at 15 fps; up to 180 sec. are seselectable.8)Time Lapse movie mode. |
| Self-timer |
Ten- or three-second duration |
| Sensitivity (equivalent film speed) |
ISO 50 equivalent; 100, 200, 400, and Auto (can be controlled in any exposure mode) |
| White balance |
1) Matrix Auto White Balance with TTL control, 2) 6-mode Manual with fine tuning (Daylight/Incandescent/Fluorescent/Cloudy/Speedlight/Shade), 3) Preset, 4) White Balance Bracketing |
| Built-in flash operating modes |
Flash modes: 1) Auto Flash, 2) Flash Cancel 3) Red Eye Reduction 4) Anytime Flash, 5) Night Portrait (Slow Sync. Flash), 6) Rear-Curtain Sync; Repeating Flash |
| Flash range |
Shooting range: approx. 0.5-4.5m (1.6-14.8 ft.) (W), approx. 0.5-2.8m (1.6-9.2 ft.) (T) |
| Terminals for external flash |
Hotshoe connects to external Nikon Speedlight SB-80DX/50DX/30/27*/23*/22s; built-in Speedlight can be canceled when using external Speedlight(s) |
| Storage media |
Media: CF Card Type I/II, 512MB/1GB Microdrive Card |
| Image recording format |
System: Exif 2.2 file (uncompressed TIFF-RGB or compressed JPEG), Design rule for camera file system (DCF), Digital Print Order Format (DPOF), QuickTime Motion JPEG (Movie, Audio) |
| Resloution Modes |
5M (2,592 x 1,944), 2M (1,600 x 1,200), 1M (1,280 x 960), PC (1,024 x 768), TV (640 x 480), 3:2 (2,592 x 1,728) selectable |
| Movie Recording |
Movie with audio: TV movie mode (VGA-size images, 640 x 480 pixels) at 15 fps; up to 70 sec., or Small movie mode (QVGA-size images, 320 x 240 pixels) at 15 fps; up to 180 sec. are selectable / Time-lapse movie mode |
| Interface |
USB interface |
| Power Source |
Power requirements One Rechargeable Li-ion Battery EN-EL1 (included), One 6V 2CR5/DL245 lithium battery (optional), AC Adapter (optional) Battery life Approx. 110 min. when using LCD monitor and EN-EL1 battery at normal temperature (20°C [68°F]) |
| Dimensions |
(W x H x D) 108 x 73 x 69mm (4.3 x 2.9 x 2.7 in.) |
| Weight |
Approx. 320g (11.3 oz.) (without battery and storage media) |
| System requirements |
Macintosh OS Mac® OS 9.0 - 9.2 (only built-in USB ports supported), Mac® OS X (10.1.3 or later) Models iMac, iMac DV, Power Macintosh® G3 (Blue & White), Power Mac G4 or later; iBook, PowerBook® G3 or later (only built-in USB ports supported) / OS Windows® 98SE, Windows® Me, Windows® 2000 Professional, Windows® XP Home Edition, Windows® XP Professional pre-installed model Models Only models with built-in USB ports supported CPU Pentium® 300MHz or higher |
| Special features |
Portrait, Party/Indoor, Night Portrait, Beach/Snow, Landscape, Sunset, Night Landscape, Museum, Fireworks Show, Close Up, Copy, Back Light, Sports, Panorama Assist, and Dawn/Dusk
User setting 1) White balance, 2) (Exposure) Metering, 3) Continuous (Shooting), 4) Best Shot Selector (BSS/AE-BSS ), 5) Image adjustment (Auto/Normal/More Contrast/Less Co ntrast), 6) Saturation control (-2 +2/Black & White), 7 User setting (two combinations of mode setting can be memorized in # 1-#2), |
