| Reception Methods |
ambient and flash, Incident Convertible to flat diffuser (lumisphere in down position)
Reflected 1° to 4° nine element zoom |
| Receptor Element |
Silicon photo diodes (incident and reflected) |
| Measuring Modes |
Ambient light
Aperture priority metering
Shutter speed priority metering
EV metering value
Flash
With synch cord (cumulative, non-cumulative)
Without synch cord (cumulative, non-cumulative)
With radio triggering (cumulative, non-cumulative) |
| Measuring Range (ISO 100) |
Ambient
Incident light: EV(-) 2 to EV22.9
Reflected light: EV3 to EV24.4
Flash
Incident light: f/0.5 to 128.9
Reflected light: f/5.6 to 128.9 |
| Repeatability |
±0.1EV or less |
| Display Readout |
Digital LCD plus LCD analog
Auto backlit LCD at EV 3 or under for 20 secs
Shutter speed and aperture are displayed along the lower edge of the viewfinder
Film speeds from ISO 3-8000 (in 1/3rd steps)
Analog Display: f/1.0 to f/128 (in 1/2 steps)
E.u (underexposure) or E.o (overexposure) indication |
| ISO Range |
ISO 3 to ISO 8000 (1/3 steps) |
| F-Stop Display Range |
Analog display f/1.0 to f/128 (in 1/2 steps)
Digital display f/0.5 to f/128.9 |
| Exposure value (EV) Range |
EV(-) 9.9 to EV40.6 (1/10 steps)
Foot-candle 0.12 to 180,000
Lux 0.63 to 190,000 |
| Reception Methods |
ambient and flash, Incident Convertible to flat diffuser (lumisphere in down position)
Reflected 1° to 4° nine element zoom |
| Shutter Speed - Flash |
1/1000 to 30 minutes (full, 1/2 or 1/3rd steps) |
| Cine Speeds |
2, 3, 4, 6, 8, 12, 16, 18, 24, 25, 30, 32, 36, 40, 48, 50, 60, 64, 72, 96, 120, 128, 150, 200, 240, 256, 300, 360 |
| Memory Function |
9 readings on analog scale (f/stop and shutter speed) with memory recall and clear feature |
| Flash analyzing function |
Percentage of flash in total exposure from 0 to 100% in 10% increments |
| Exposure Calculating Function |
Exposure compensation ± 9.9EV for incident and reflected independently
Calibration compensation ± 1.0EV for incident and reflected independently
Filter compensation ±5.0EV on ISO2 |
| Brightness Difference Function |
Flash or ambient light evaluation (original value vs new measurement) |
| Multiple Flash |
Unlimited flash readings (Only last digit is displayed when more than ten flash exposures are measured.) |
| Power |
3.0Vx1 (CR123A lithium battery) |
| Dimensions |
3.5W x 6.7H x 1.9D" (90W x 170H x 48D mm) |
| Receptor Element |
Silicon photo diodes (incident and reflected) |
| Notes & Special Features |
Average function: Flash and ambient up to 9 measurements
All weather design: JIS standard water resistance class 4, splash-proof type
Calibration constant Incident metering: Lumisphere C=340
Flat diffuser C=250
Reflected metering: K=12.5
Custom Programs 11 custom program settings
Radio Triggering (Optional)
Radio technology Complex 16/24 bit digitally coded
Range Up to 100 ft from transmitter to receiver
Channels 1-16 standard, 17 to 32 "Quad Triggering" |
| Measuring Modes |
Ambient light
Aperture priority metering
Shutter speed priority metering
EV metering value
Flash
With synch cord (cumulative, non-cumulative)
Without synch cord (cumulative, non-cumulative)
With radio triggering (cumulative, non-cumulative) |
| Measuring Range (ISO 100) |
Ambient
Incident light: EV(-) 2 to EV22.9
Reflected light: EV3 to EV24.4
Flash
Incident light: f/0.5 to 128.9
Reflected light: f/5.6 to 128.9 |
| Repeatability |
±0.1EV or less |
| Display Readout |
Digital LCD plus LCD analog
Auto backlit LCD at EV 3 or under for 20 secs
Shutter speed and aperture are displayed along the lower edge of the viewfinder
Film speeds from ISO 3-8000 (in 1/3rd steps)
Analog Display: f/1.0 to f/128 (in 1/2 steps)
E.u (underexposure) or E.o (overexposure) indication |
| ISO Range |
ISO 3 to ISO 8000 (1/3 steps) |
| F-Stop Display Range |
Analog display f/1.0 to f/128 (in 1/2 steps)
Digital display f/0.5 to f/128.9 |
| Exposure value (EV) Range |
EV(-) 9.9 to EV40.6 (1/10 steps)
Foot-candle 0.12 to 180,000
Lux 0.63 to 190,000 |
| Shutter Speed - Ambient |
30 minutes to 1/8000 second (full, 1/2 or 1/3 stops) |
| Shutter Speed - Flash |
1/1000 to 30 minutes (full, 1/2 or 1/3rd steps) |
| Cine Speeds |
2, 3, 4, 6, 8, 12, 16, 18, 24, 25, 30, 32, 36, 40, 48, 50, 60, 64, 72, 96, 120, 128, 150, 200, 240, 256, 300, 360 |
| Memory Function |
9 readings on analog scale (f/stop and shutter speed) with memory recall and clear feature |
| Flash analyzing function |
Percentage of flash in total exposure from 0 to 100% in 10% increments |
| Exposure Calculating Function |
Exposure compensation ± 9.9EV for incident and reflected independently
Calibration compensation ± 1.0EV for incident and reflected independently
Filter compensation ±5.0EV on ISO2 |
| Brightness Difference Function |
Flash or ambient light evaluation (original value vs new measurement) |
| Multiple Flash |
Unlimited flash readings (Only last digit is displayed when more than ten flash exposures are measured.) |
| Power |
3.0Vx1 (CR123A lithium battery) |
| Dimensions |
3.5W x 6.7H x 1.9D" (90W x 170H x 48D mm) |
| Weight |
9.5 oz. (268g) |
| Notes & Special Features |
Average function: Flash and ambient up to 9 measurements
All weather design: JIS standard water resistance class 4, splash-proof type
Calibration constant Incident metering: Lumisphere C=340
Flat diffuser C=250
Reflected metering: K=12.5
Custom Programs 11 custom program settings
Radio Triggering (Optional)
Radio technology Complex 16/24 bit digitally coded
Range Up to 100 ft from transmitter to receiver
Channels 1-16 standard, 17 to 32 "Quad Triggering" |
