Full digital control of all functions! Full digital control by 2 - way remote, 4 Studios, 16 station control by PC!
Today's digital workflow and camera systems demand greater accuracy at all power settings with an extended power range to cover extreme requirements. Precise repeatability, whether at 2 second or 2 week intervals is possible with the ultra-stable electronics controlled by accurate digital displays.
Elinchrom performance characteristics now exceed the most demanding criteria. The revised range of Style Digital units, with power variation from 1200 Ws to 9 Ws, offer optional digital 2-way remote control and provide the possibility to interface with PC workstations, combining seamlessly with the new digital packs.
|Power (Watt Seconds)||From 18w to 600w|
|Guide Number||F-stop, (1m, 100 ISO, 1/250s; Reflector 48°) = 90.1|
|Flash Duration||Flash duration @ t 0,5 = 1/2050s|
|Recycling Time||Recycling, min. / max. 115 V = 0.3 to 1.5s|
|Fan Cooled||Yes, 1 fan|
|Modeling Lamp||Modelling lamp 115 V USA 150 W - BA 15 D|
|Voltage||Product code, 115 V - 140 V 50 - 60 Hz #20726|
|User replaceable flashtube||Yes: Flashtube code 24029|
|Dimensions||length x diameter in cm 21 x 14 / 8.26 inches x 5.5 inches|
|Weight||Weight in kg: 2.6 / 5.73 lbs.|
|Special Features||Variable flash power, in f-stops stepless 6 f-stops 1/32 -1/1
Voltage stabilization +/- 0.5 %
Sync voltage 5 V
Interface for PC (Mac in development) optional
Plug for Remote control: Yes
|Notes||Tolerances of specifications and components conform to IEC and CE standards. Technical data subject to change.
The listed values can differ due to tolerances in components or measuring instruments. Errors and omissions excepted.
