With output control in truly-accurate 1/10th stop increments and the ability to interface with Mac or PC systems, the new Digital Style RX monoblocs outperform the competition.
Today's digital workflow and camera systems demand greater accuracy at all powersettings with an extended power range to cover extreme requirements. Precise repeatability, whether at 2 second or 2 week intervals is possible with the ultra-stable electronics controlled by accurate digital displays.
The Digital Style RX series is Elinchrom's true answer to the strict demands of the Digital Photographer. Applying the renowned Elinchrom reliability, consistency and color temperature, the new RX series is even more precise!
Full Digital Control of All Functions! Full Digital Control by 2 Way Remote 4 Studios, 16 Station Control by PC or Mac! Elinchrom performance characteristics now exceed the most demanding criteria. The revised range of Style RX units, with power variation from 1200 Ws to 9 Ws, offer optional digital 2-way remote control and provide the possibility to interface with Mac and PC workstations, combining seamlessly with the new Digital 1200RX and Digital 2400RX Power Packs.
|Power (Watt Seconds)||
300RX: From 9w to 300w
600RX: From 18w to 600w
300RX: F-stop, (1m, 100 ISO, 1/250s; Reflector 48°) = 64.1
600RX: F-stop, (1m, 100 ISO, 1/250s; Reflector 48°) = 90.1
RX300: Flash duration @ t 0,5 = 1/2850s
RX600: Flash duration @ t 0,5 = 1/2050s
RX300: Recycling, min. / max. 230 V 0.25 to 0.8s
Recycling, min. / max. 115 V 0.25 - 0.8 s
RX600: Recycling, min. / max. 115 V = 0.3 to 1.5s
|Fan Cooled||Yes, 1 fan|
|Modeling Lamp||Modelling lamp 115 V USA 150 W - BA 15 D|
|Voltage||115 V - 240 V 50 - 60 Hz|
|User replaceable flashtube||Yes: Flashtube code 24029|
|Dimensions||Length x Diameter in cm 21 x 14 / 8.26 inches x 5.5 inches|
RX300: Kg: 2.3 / 5.07 lbs.
RX600: Kg: 2.3 / 5.07 lbs.
|Special Features||Variable flash power, in f-stops stepless 6 f-stops 1/32 -1/1
Voltage stabilization +/- 0.5 %
Sync voltage 5 V
Interface for PC (Mac in development) optional
Plug for Remote control: Yes
|Notes||Tolerances of specifications and components conform to IEC and CE standards. Technical data subject to change.
The listed values can differ due to tolerances in components or measuring instruments. Errors and omissions excepted.
