| Records Onto |
SD/SDHC/SDXC Memory Card |
| Recording Format |
1080 / 60p : MPEG-4 AVC/H.264 (original format)
HA / HG / HX / HE : MPEG-4 AVC/H.264 (AVCHD standard compliant) / JPEG |
| Image Sensor (Total) |
1/4.1" MOS x 3 |
| Total Pixels |
9.15 megapixels (3.05 megapixels x 3) |
| F Value |
F1.5(WIDE)/2.8(TELE) |
| Optical Zoom |
12x |
| Intelligent Zoom |
18x |
| Digital Zoom |
30x / 700x (The maximum value of zoom magnification) |
| Focal Length |
3.45-41.4mm |
| Filter Diameter |
46mm |
| 35mm Film Camera Equivalent |
35.0-420mm (16:9) [Motion Image]
35.7-428mm (3:2), 35.0-420mm (16:9), 38.8-466mm (4:3) [Still Image] |
| Lens Type |
Leica Dicomar Lens |
| Image Stabilizer |
HYBRID O.I.S. [Optical Image Stabilization] |
| Still Picture Recording:4:3 |
12.2 megapixels (4032 x 3024), 7.7 megapixels (3200 x 2400), 4.9 megapixels (2560 x 1920), 0.3 megapixels (640 x 480) [4:3] |
| Still Picture Recording:3:2 |
14.2 megapixels (4608 x 3072), 8.6 megapixels (3600 x 2400), 5.5 megapixels (2880 x 1920) [3:2] |
| Still Picture Recording:16:9 |
13.3 megapixels (4864x2736), 8.3 megapixels (3840 x 2160), 5.3 megapixels (3072 x 1728) [16:9] |
| Shutter Speed: Motion Image |
[60i / 60p] Auto Slow Shutter ON : 1/30-1/8000 , video flash: 1/30-1/500 OFF : 1/60-1/8000, video flash: 1/60-1/500
[24P] Auto Slow Shutter ON : 1/24-1/8000 , video flash: 1/24-1/500 OFF : 1/48-1/8000, video flash: 1/48-1/500 |
| Shutter Speed: Still Image |
1/2-1/2000, video flash: 1/2-1/500 |
| Minimum Illumination |
1.6 lx (1/30 Low Light scene mode)
1 lx (Color Night Rec) |
| Standard Illumination |
1400 lx |
| Focus |
Auto/Manual |
| White Balance |
Auto/Indoor1/Indoor2/Sunny/Cloudy/White Set |
| Iris |
Auto/Manual |
| Backlight Compensation |
Yes |
| Electronic Viewfinder (EVF) |
Yes |
| LCD Monitor |
3.0" Wide LCD (230,400 dots) |
| Simultaneous Recording |
13.3 megapixels (4864 x 2736), 8.3 megapixels (3840 x 2160) , 2.1 megapixels (1920x1080) [16:9] |
| Creating Still Picture |
2.1 megapixels (1920 x 1080) [16:9] (from Motion Picture) |
| Microphone |
5.1ch Surround, Zoom and Focus Microphone |
| Speaker |
Dynamic type |
| On-Screen Display Language |
English / French / Spanish |
| Flash |
Yes |
| Media Remaining Indication |
Yes |
| Signal System |
1080 / 60p, 1080 / 60i |
| Recording Mode |
1080/60p (28Mbps/VBR),(1920x1080)
HA(17Mbps/VBR),(1920x1080)
HG(13Mbps/VBR),(1920x1080)
HX(9Mbps/VBR),(1920x1080)
HE(5Mbps/VBR),(1920x1080) |
| Playback Mode |
1080 / 60p (28Mbps / VBR) , (1920 x 1080)
HA (17Mbps / VBR) , (1920 x 1080)
HG (13Mbps / VBR) , (1920 x 1080)
HX (9Mbps / VBR) , (1920 x 1080)
HE (5Mbps / VBR) , (1920 x 1080) |
| Image Sensor (Effective)-Motion Image |
7.59 megapixels (2.53 megapixels x 3) [16:9] |
| Image Sensor (Effective)-Still Image |
7.89 megapixels (2.63 megapixels x 3) [3:2]
7.59 megapixels (2.53 megapixels x 3) [16:9]
6.96 megapixels (2.32 megapixels x 3) [4:3] |
| Compression (Recording Format) |
1080 / 60p : MPEG-4 AVC/H.264 (original format)
HA / HG / HX / HE : MPEG-4 AVC/H.264 (AVCHD standard compliant) |
| Audio Compression |
Dolby Digital (5.1ch / 2ch) |
| DPOF |
Max. 999 images |
| HDMI |
Yes (mini) |
| USB |
2.0 Hi-Speed |
| Microphone (stereo mini) |
Yes |
| Headphone (Stereo mini) |
Yes |
| Accessory Shoe |
Yes (Cold) |
| AC Adaptor |
Yes |
| USB Cable |
Yes |
| Stylus Pen |
Yes |
| IR Remote |
Yes |
| Included Software |
HD Writer AE 2.6T |
| Rechargeable Battery Pack |
min. 1250 mAh / Lithium-Ion |
| Power Supply |
DC7.2V / 9.3V |
| Power Consumption |
Max. 6.0W (Recording) |
| AV Multi |
Yes |
| AV Multi Cable |
Yes |
| AC Cable |
Yes |
| DC Cable |
Yes |
| Lens hood |
Yes |
| Shoe adaptor |
Yes |
| HDMI cable (mini) |
Yes |
| 3D Conversion Lens (VW-CLT1) |
Yes |
| F Value |
F3.2 (with 3D Conversion Lens (VW-CLT1)) |
| Focal Length |
2.5mm (with 3D Conversion Lens (VW-CLT1)) |
| 35mm Film camera Equivalent |
58mm (16:9) [Motion Image] (with 3D Conversion Lens (VW-CLT1)) |
| Minimum Illumination |
28 lx (1/30) (with 3D Conversion Lens (VW-CLT1)) |
| Dimension |
66 x 69 x 138 [mm] ( 2.59 x 2.71 x 5.43 [inch])
Without lens: 78 x 59 x 97 [mm] ( 3.07 x 2.32 x 3.82 [inch]) |
| Weight |
Without Battery: Approx. 375g ( 0.83lb)
Without Lens Cap: Approx. 195g ( 0.43lb) |
